Quick Details
-
Model Number:
-
DN15~DN1800
-
Standard or Nonstandard:
-
Standard
-
application:
-
link pipes
-
Packing:
-
Customers' Requirements
-
Name:
-
Carbon Steel Forged Flange
-
Surface:
-
Anti-rust Oil
-
Surface treatment:
-
Antirust Oil
-
Technics:
-
Forget
-
Certificate:
-
ISO9001
-
Pressure:
-
Class150/300/600/9001500/2500
Quick Details
-
Standard:
-
ANSI, ASME
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RC
-
Model Number:
-
DN15~DN1800
-
Standard or Nonstandard:
-
Standard
-
application:
-
link pipes
-
Packing:
-
Customers' Requirements
-
Name:
-
Carbon Steel Forged Flange
-
Surface:
-
Anti-rust Oil
-
Surface treatment:
-
Antirust Oil
-
Technics:
-
Forget
-
Certificate:
-
ISO9001
-
Pressure:
-
Class150/300/600/9001500/2500
Products Overviews:
Slip-On flanges or SO flanges are commonly lower in price than weld-neck flanges, and to this effect are a popular choice for our customers. However, customers should bear in mind that this initial cost saving may be diminished by the additional cost of the two fillet welds required for proper installation. Moreover, weld-neck flanges have a higher life expentancy than slip-on flanges under duress.
The slip-on flange is positioned so the inserted end of the pipe or fitting is set short of the flange face by the thickness of the pipe wall plus 1/8 of an inch, which thus allows for a fillet weld inside the SO flange equal without doing any damage to the flange face. The back or outside of the slip-on flange or SO flange is also welded with a fillet weld.
|
FLANGES |
|
|
Production Type |
Slip-on welding flange; welding neck flange; socket welding flange; threaded flange; lap joint flange; blind flange etc. |
|
Size Range |
From 1/2" up to 60" |
|
Schedule |
SCH STD, XS, XXS, SCH 10 ~ SCH 160 |
|
Material Code: |
|
|
1 .Carbon steel |
ASTM A105, ASTM A350 LF1/ LF2/LF3, ASTM |
|
ASTM A694 F42/F46/F52/F56/F60/F65/F70 |
|
|
2 .Alloy steel |
ASTM A182 F1, F5, F7, F9, F11, F12, F22, F91 |
|
3 . S tainless steel |
ASTM A182 F304/304L, F316/316L, F321, F347, |
|
S tandards |
ANSI, ISO, JIS, DIN, BS,GB, SH, HG,QOST,ETC. |
|
Certification |
ISO9001:2000 , API , CE |
|
Applications range |
Petroleum, chemical, power, gas, metallurgy, shipbuilding , construction,water etc. |
|
Packaging: |
Wooden Cases or pallet or as per customers requirement |
|
Delivery Time: |
At the earliest ,within the period required by customer. |
Our products are with good quality and reasonable price, welocme your nquiry at any time!!!
