Quick Details
-
Warranty:
-
30 Years
-
Brand Name:
-
DAH solar
-
Model Number:
-
DHM72X10
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Name:
-
solar panel cells 182mm monocrystalline 500 watt solar pv panel
-
Application:
-
Solar panel system
-
Cell type:
-
Mono
-
Color:
-
Blue, Black
-
Frame:
-
Anodized Aluminium Alloy
-
Backsheet:
-
White/Black
-
Weight:
-
23.5kg
-
Waterproof:
-
IP68 Rated
-
Connector:
-
Compatible Connector
-
Junction Box:
-
IP68 Rated
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
All Black, Bifacial, Half Cell, PERC
-
Panel Efficiency:
-
22%
-
Warranty:
-
30 Years
-
Brand Name:
-
DAH solar
-
Model Number:
-
DHM72X10
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Name:
-
solar panel cells 182mm monocrystalline 500 watt solar pv panel
-
Application:
-
Solar panel system
-
Cell type:
-
Mono
-
Color:
-
Blue, Black
-
Frame:
-
Anodized Aluminium Alloy
-
Backsheet:
-
White/Black
-
Weight:
-
23.5kg
-
Waterproof:
-
IP68 Rated
-
Connector:
-
Compatible Connector
-
Junction Box:
-
IP68 Rated
|
Maximum Power(Pmax)
|
525W
|
530W
|
535W
|
540W
|
|||
|
Open-circuit Voltage (Voc)
|
49.2V
|
49.4V
|
49.6V
|
49.8V
|
|||
|
Maximum Power Voltage(Vmp)
|
41.4V
|
41.6V
|
41.8V
|
42V
|
|||
|
Short-circuit Current (Isc)
|
13.48A
|
13.54A
|
13.60A
|
13.66A
|
|||
|
Maximum Power Current (Imp)
|
12.68A
|
12.74A
|
12.80A
|
12.86A
|
|||
|
Solar Panel Efficiency
|
20.31%
|
20.51%
|
20.70%
|
20.89%
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|
|||
|
Standard Test Environment
|
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
|
|
|
|
|||
|
Maximum Power(Pmax)
|
545W
|
550W
|
555W
|
560W
|
|||
|
Open-circuit Voltage (Voc)
|
50V
|
50.0V
|
50.4
|
50.6V
|
|||
|
Maximum Power Voltage(Vmp)
|
42.2V
|
42.4V
|
42.6
|
42.8V
|
|||
|
Short-circuit Current (Isc)
|
13.72A
|
13.78A
|
13.84A
|
13.90A
|
|||
|
Maximum Power Current (Imp)
|
12.91A
|
12.97A
|
13.03A
|
13.08A
|
|||
|
Solar Panel Efficiency
|
21.09%
|
21.28%
|
21.48%
|
21.67%
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|
|||
|
Standard Test Environment
|
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
|
|
|
|
|||
