Quick Details
-
Place of Origin:
-
Anhui, China
-
Cell size:
-
158.75*31.75mm
-
Panel Dimensions:
-
1750*400*4mm
-
Panel Efficiency:
-
15%
-
Product name:
-
Flexible Solar Panles
-
Type:
-
Flexible
-
waterproof:
-
IP68
-
Operating temperature:
-
-40°C~+85°C
-
Application:
-
Solar Power System
-
Connector:
-
PV EVO2 / TS4
-
Certificate:
-
CE TUV
-
Size:
-
1750x400x4mm
-
wright:
-
3kg
-
OEM:
-
Accept OEM Production
Quick Details
-
Power:
-
105W/110W
-
Brand Name:
-
SUNWAY
-
Model Number:
-
SK-105W
-
Place of Origin:
-
Anhui, China
-
Cell size:
-
158.75*31.75mm
-
Panel Dimensions:
-
1750*400*4mm
-
Panel Efficiency:
-
15%
-
Product name:
-
Flexible Solar Panles
-
Type:
-
Flexible
-
waterproof:
-
IP68
-
Operating temperature:
-
-40°C~+85°C
-
Application:
-
Solar Power System
-
Connector:
-
PV EVO2 / TS4
-
Certificate:
-
CE TUV
-
Size:
-
1750x400x4mm
-
wright:
-
3kg
-
OEM:
-
Accept OEM Production
Product Description
|
Mechanical Parameters
|
|
|
|
Cell Size
|
Mono PERC 158.75mm*31.75mm
|
|
|
Module Size
|
1750×400×4mm (L×W×H)
|
|
|
Glass Thickness
|
4.0mm
|
|
|
Module Weight
|
3.0kg
|
|
|
Output Cable
|
4mm², cable length 300mm (can be customized)
|
|
|
Connector
|
PV compatible
|
|
|
Junction Box
|
IP68, 2 bypass diodes
|
|
|
Back Color
|
Black / White
|
|
|
Electrical Parameters(STC*)
|
|
|
||
|
Nominal Max.Power(Pmax/w)
|
105
|
110
|
||
|
Open Circuit Voltage(Voc/V)
|
39.26
|
39.94
|
||
|
Short Circuit Current(Isc/A)
|
3.62
|
3.67
|
||
|
Operating Voltage(Vmp/V)
|
31.53
|
32.54
|
||
|
Operating Current(Imp/A)
|
3.33
|
3.38
|
||
|
Module Efficiency(%)
|
15.0
|
15.7
|
||
|
STC*(Standard Test Condition):Irradiance 1000W/m²,Cell Temperature25℃,AM1.5
|
|
|
||
|
Electrical Parameters(NMOT*)
|
|
|
||
|
Nominal Max.Power(Pmax/W)
|
78
|
82
|
||
|
Open Circuit Voltage(Voc/V)
|
36.32
|
36.94
|
||
|
Short Circuit Current(Isc/A)
|
2.92
|
2.96
|
||
|
Operating Voltage(Vmp/V)
|
29.33
|
30.27
|
||
|
Operating Current(Imp/A)
|
2.66
|
2.70
|
||
|
NMOT*(Nominal Module Operating Temperature):Irradiance 800W/m²,Ambient Temperature20℃,AM1.5,Wind Speed 1m/s
|
|
|
||
