Quick Details
-
Warranty:
-
25 years warranty
-
Brand Name:
-
OREE
-
Model Number:
-
PERC - 550W
-
Place of Origin:
-
Shandong, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Cell Type:
-
P-type Monocrystalline
-
Glass:
-
3.2mm High Transmission
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
28kg
-
Cable:
-
4mm2
-
Junction Box:
-
IP 68, Three Diodes
-
Connector:
-
MC4 Compatible Connector
-
Application Level:
-
Class A
-
Packaging:
-
31 Pcs/pallet, 620 Pcs/40'HQ
-
Certificate:
-
CE TUV INMETRO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, MBB, High-efficiency, Waterproof
-
Panel Efficiency:
-
21.28%
-
Warranty:
-
25 years warranty
-
Brand Name:
-
OREE
-
Model Number:
-
PERC - 550W
-
Place of Origin:
-
Shandong, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Cell Type:
-
P-type Monocrystalline
-
Glass:
-
3.2mm High Transmission
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
28kg
-
Cable:
-
4mm2
-
Junction Box:
-
IP 68, Three Diodes
-
Connector:
-
MC4 Compatible Connector
-
Application Level:
-
Class A
-
Packaging:
-
31 Pcs/pallet, 620 Pcs/40'HQ
-
Certificate:
-
CE TUV INMETRO
Product Description
Specification
|
SPECIFICATIONS
|
|
|
|
|
|
|
||||||
|
Module Type
|
ORM72T31
-525/MR
|
ORM72T31
-530/MR
|
ORM72T31
-535/MR
|
ORM72T31
-540/MR
|
ORM72T31
-545/MR
|
ORM72T31
-550/MR |
||||||
|
|
STC/NOCT
|
STC/NOCT
|
STC/NOCT
|
STC/NOCT
|
STC/NOCT
|
STC/NOCT
|
||||||
|
Maximum Power (W)
|
525/391
|
530/394
|
535/398
|
540/402
|
545/405
|
550/409
|
||||||
|
Voltage Mpp (Vmp/V)
|
41.24/38.30
|
41.53/38.55
|
41.82/38.79
|
42.12/39.04
|
42.41/39.28
|
42.71/39.49
|
||||||
|
Current Mpp (Imp/A)
|
12.73/10.20
|
12.76/10.23
|
12.79/10.26
|
12.82/10.29
|
12.85/10.32
|
12.88/10.36
|
||||||
|
Open circuit voltage (Voc/V)
|
49.05/45.96
|
49.20/46.11
|
49.35/46.27
|
49.51/46.42
|
49.69/46.58
|
49.88/46.74
|
||||||
|
Short circuit current (Isc/A)
|
13.61/11.01
|
13.68/11.08
|
13.75/11.14
|
13.82/11.20
|
13.89/11.27
|
13.97/11.34
|
||||||
|
Module efficieney (%)
|
20.31%
|
20.51%
|
20.7%
|
20.89%
|
21.09%
|
21.28%
|
||||||
*STC: Irradiance 1000W/㎡, Environment Temperature 25℃, Air Mass AM 1.5G
*STC: Irradiance 800W/㎡, Cell Temperature20℃, Air Mass AM 1.5G, Wind Speed 1m/s
only 0.52% subsequent annual degradation
