Quick Details
-
Dimension:
-
2434*1253*1481
-
Place of Origin:
-
Shandong, China
-
Engine:
-
ODES V-Twin cylinder, 4-stroke
-
Rated Power:
-
63.7kw
-
Certificate:
-
EPA, T3a, T3b
-
EPS:
-
Available
-
Clutch:
-
Canadian CV-Tech
Quick Details
-
Displacement:
-
>300cc
-
Brand Name:
-
IM
-
Tire Size:
-
26*9-14/26*11-14
-
Dimension:
-
2434*1253*1481
-
Place of Origin:
-
Shandong, China
-
Engine:
-
ODES V-Twin cylinder, 4-stroke
-
Rated Power:
-
63.7kw
-
Certificate:
-
EPA, T3a, T3b
-
EPS:
-
Available
-
Clutch:
-
Canadian CV-Tech
Recommend Products
|
Model
|
1000S
|
1000L
|
|
|
Engine Type
|
V-Twin cylinder, 4-stroke
|
V-Twin cylinder, 4-stroke
|
|
|
Max. Power
|
63.7KW/6500rpm
|
63.7KW/6500rpm
|
|
|
Max. Torque
|
101N.m/5500rpm
|
101N.m/5500rpm
|
|
|
Vehicle Mode
|
Short Wheelbase
|
Long Wheelbase
|
|
|
Dimensions
|
2298*1246*1335mm
|
2450*1246*1400mm
|
|
|
Structure Weight
|
400kg
|
420kg
|
|
|
Wheelbase
|
1348mm
|
1508mm
|
|
|
Racks Capacity(Front/Rear)
|
34kg/68kg
|
34kg/68kg
|
|
|
Towing Capacity
|
600kg
|
600kg
|
|
|
Person Capacity
|
1
|
2
|
|
|
Front/Rear Tread
|
1010/970mm
|
1010/970mm
|
|
|
Front/Rear Wheel
|
26*9-14/26*11-14 alloy Rim
|
26*9-14/26*11-14 alloy Rim
|
|
|
Ground Clearance
|
255mm
|
255mm
|
|
|
Front/Rear Brake
|
Disc brake
|
Disc brake
|
|
|
Transmission
|
CVT, L-H-N-R-P
|
CVT, L-H-N-R-P
|
|
|
Front/Rear Suspension
|
Double A-Arm Independent
|
Double A-Arm Independent
|
|
|
Front/Rear Shock
|
Preloaded, Oil Damped
|
Preloaded, Oil Damped
|
|
|
Fuel Tank Capacity
|
22L
|
22L
|
|
|
Certificate
|
EPA, T3a, T3b
|
EPA, T3a, T3b
|
|
|
Color Available
|
Black, White
|
Black, White
|
|
|
Standard Configurations
|
Front/Rear plastic racks, 14" alloy rims with 26" tires, Canadian CV-tech Clutch, LED lights, aluminum foot teeth pedal, rear seatrest + handgrips(long wheelbase available)
Including:
1).Winch 3500lbs;
2).Power Steering;
3).Towing hitch bar;
4).andle bar protector
5).Side fender
|
|
|
|
Optional Configurations
|
6).Front Bumper;
7).Rear Bumper;
8).Hydraulic w/Nitrogen Assist;
9). Color options: Metallic gray, Camo, Blue, Red, Green
|
|
|
