Quick Details
-
Power:
-
19.6kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LOONGSHEEN
-
Maximum Digging Height:
-
3900 mm
-
Maximum Digging Depth:
-
2500 mm
-
Machine Weight:
-
3000 kg
-
Max Digging Radius:
-
4040 mm
-
Rated Speed:
-
2.6 km/h
-
Warranty of core components:
-
1 year
-
Swing angel of boom (L/R):
-
70°/50°
-
Digging bucket capacity:
-
0.095cbm
-
Digging bucket width:
-
500mm
-
Engine:
-
3TNV88
-
Rated power:
-
19.6kw/2200r/min
-
Main pump:
-
Triple Pump
-
Max.rpm of the pump:
-
2500r/min
-
Pressure:
-
18Mpa
-
Pump displacement:
-
28ml/r
-
Track width:
-
230mm
Quick Details
-
Operating Weight:
-
3000KG
-
Bucket capacity:
-
0.095cbm
-
Engine Brand:
-
YANMA
-
Power:
-
19.6kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LOONGSHEEN
-
Maximum Digging Height:
-
3900 mm
-
Maximum Digging Depth:
-
2500 mm
-
Machine Weight:
-
3000 kg
-
Max Digging Radius:
-
4040 mm
-
Rated Speed:
-
2.6 km/h
-
Warranty of core components:
-
1 year
-
Swing angel of boom (L/R):
-
70°/50°
-
Digging bucket capacity:
-
0.095cbm
-
Digging bucket width:
-
500mm
-
Engine:
-
3TNV88
-
Rated power:
-
19.6kw/2200r/min
-
Main pump:
-
Triple Pump
-
Max.rpm of the pump:
-
2500r/min
-
Pressure:
-
18Mpa
-
Pump displacement:
-
28ml/r
-
Track width:
-
230mm
2.The mini excavator can attach hammer/ auger /ripper/ 350mm bucket /490mm bucket /600mm bucket / 800mm bucket /loader bucket /Quick hitch /grabber .
3.The mini excavator are smart and superior in performance, low in fuel consumption .
4.It is suitable to be used for small works, small projects, in garden, farmland, municipal works,vegetable greenhouse, digging trench .
5.The platform can rotate 360 degrees
|
Operating Weight |
3000kg |
|
Digging bucket capacity |
0.095cbm |
|
Digging bucket width |
500mm |
|
|
|
|
Engine |
3TNV88 |
|
Rated power |
19.6kw/2200r/min |
|
|
|
|
Main pump |
Triple Pump |
|
Max.rpm of the pump |
2500r/min |
|
Pressure |
18Mpa |
|
Pump displacement |
28ml/r |
|
|
|
|
Track width |
230mm |
|
Track length on ground |
2300 mm |
|
Track gauge |
1150mm |
|
Machine length |
4180 mm |
|
Machine width |
1400 mm |
|
Machine height |
2128 mm |
|
Ground clearance |
458 mm |
|
Whole machine weight |
2600kg |
|
Ground pressure |
38 kpa |
|
Max. Digging depth |
2500 mm |
|
Max. Digging height |
3900 mm |
|
Max. Dumping height |
2600 mm |
|
Max. Digging radius on ground |
4040 mm |
|
|
|
|
Swing angel of boom (L/R) |
70°/50° |
|
Travel speed |
2.6 km/h |
|
Grade ability |
25° |
|
Rotation degrees |
360° |
