Quick Details
-
Horsepower:
-
< 150hp
-
Cargo Tank Type:
-
Column plate
-
Gross Vehicle Weight:
-
<=5000 kg
-
Drive Wheel:
-
2x2
-
After-sales Service Provided:
-
Video technical support
-
Brand Name:
-
SRM
-
Place of Origin:
-
China
-
Forward Shift Number:
-
1
-
Size:
-
5130*1730*2000
-
Cargo Tank Dimension:
-
3960x1560x1825
-
Battery:
-
Lithium iron phosphate battery
-
L*W*H:
-
3960x1560x1825 mm
-
Wheelbase:
-
3400mm
-
Front/Rear base:
-
1490/1490mm
-
Max. speed:
-
90km/h
-
Motor:
-
Permanent Magnet Sychronous Motor
-
Motor type:
-
TZ185XS022
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 6
-
Market Segement:
-
Part-load transportation
-
Horsepower:
-
< 150hp
-
Cargo Tank Type:
-
Column plate
-
Gross Vehicle Weight:
-
<=5000 kg
-
Drive Wheel:
-
2x2
-
After-sales Service Provided:
-
Video technical support
-
Brand Name:
-
SRM
-
Place of Origin:
-
China
-
Forward Shift Number:
-
1
-
Size:
-
5130*1730*2000
-
Cargo Tank Dimension:
-
3960x1560x1825
-
Battery:
-
Lithium iron phosphate battery
-
L*W*H:
-
3960x1560x1825 mm
-
Wheelbase:
-
3400mm
-
Front/Rear base:
-
1490/1490mm
-
Max. speed:
-
90km/h
-
Motor:
-
Permanent Magnet Sychronous Motor
-
Motor type:
-
TZ185XS022
Details
Specification
|
Edition
|
Tdfsk k01
|
|
L*W*H
|
3960x1560x1825mm
|
|
Container size
|
3000*1685*370mm
|
|
Wheelbase
|
3400mm
|
|
Front/Rear base
|
1490/1490mm
|
|
Front/Rear overhang
|
675/1015mm
|
|
Number of wheel
|
4
|
|
Curb Weight
|
1580kg
|
|
Rated Payload
|
1495kg
|
|
Gross Weight
|
3205kg
|
|
The number of passenger Seats
|
2
|
|
Front/rear tyre size
|
195/70R15C
|
|
Maxium speed
|
90km/h
|
|
Gradeability
|
>20
|
|
WLTC Range
|
280（53 kWh）
|
|
Minimum ground clearance
|
Full Load 160mm
|
|
Number of door
|
2
|
|
Battery
|
Lithium iron phosphate battery
|
|
Energy Density
|
≥140Wh/kg
|
|
Charging Power
|
●6.6kw/●11kw
|
|
Voltage of the motor
|
237
|
|
Rated Pwer
|
30KW
|
|
Max Net pwer
|
60KW
|
|
Max Torque
|
220N.m
|
|
Drive
|
LHD
|
