- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Btutest
-
Model Number:
-
ZDHW-HN5000A
-
Name:
-
Oxygen bomb calorimeter
-
Reference heat capacity:
-
approximately 10500 (J/K)
-
Ignition voltage:
-
AC: 24V
-
Ignition time:
-
6 minutes ignition
-
Resolution:
-
0.0001 ℃
-
Temperature measurement range:
-
0.0000 ℃ -40.000 ℃
-
Power supply:
-
220V ± 10% 50Hz
-
Instrument power:
-
40W
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Btutest
-
Model Number:
-
ZDHW-HN5000A
-
Name:
-
Oxygen bomb calorimeter
-
Reference heat capacity:
-
approximately 10500 (J/K)
-
Ignition voltage:
-
AC: 24V
-
Ignition time:
-
6 minutes ignition
-
Resolution:
-
0.0001 ℃
-
Temperature measurement range:
-
0.0000 ℃ -40.000 ℃
-
Power supply:
-
220V ± 10% 50Hz
-
Instrument power:
-
40W
Product Description
Oxygen bomb calorimeter
Description:
The calorimeter is suitable for measuring the calorific value of combustible materials such as coal, coke, petroleum, cement raw materials, brick billets, and other solid or liquid materials in industries such as power, coal, metallurgy, petrochemical, quality inspection, environmental protection, cement, papermaking, geological exploration, and research institutes. It meets the requirements of the national standard GB/T213-2008 "Method for Measuring the calorific value of coal". It is the main instrument in the coal quality laboratory.
Features：
1. Adopting a modular 24 bit AD temperature acquisition circuit, ensuring temperature measurement accuracy of 1/10000 bit.
2. The temperature measurement module adopts electronic components with ultra-low temperature drift characteristics, ensuring the stability of the test results.
3. Using embedded ARM as the main control chip, equipped with a 7-inch true color touch LCD screen and mouse device, achieving simpler and more flexible operation; Direct human-computer interaction method, more convenient to use.
4. Equipped with powerful data processing functions and scalability of computers, it achieves perfect expression of instruments. The query and printing of historical data has become simple and easy, providing compatible possibilities for future device networking and data sharing.
5. It has the same data processing speed as the previous "personal computer+controller" mode, enhancing reliability.
6. Real time cooling correction, with loose requirements for environmental temperature. Sulfur, hydrogen, and water data can be supplemented and automatically converted into high and low calorific values after the experiment is completed, which is more in line with the conventional experimental process.
7. The experimental process of water injection, drainage, stirring, ignition, temperature collection, calculation, calibration, and printing is fully automatic, avoiding human error, and greatly improving accuracy and precision.
8. The display platform adopts a large-sized color LCD touch screen display, which displays a rich, intuitive, and clear amount of information, and supports the retrieval of files or documents. You can view the national standard requirements, experimental methods, and steps for coal testing methods.
9. The integrated design of the equipment makes it easy to install and replace, and its performance is more reliable.
Specification
|
Reference heat capacity
|
approximately 10500 (J/K)
|
|
Outer bucket water capacity
|
approximately 30L
|
|
Inner bucket water capacity
|
approximately 2.3 L
|
|
Ignition voltage:
|
AC: 24V
|
|
Ignition time
|
6 minutes ignition
|
|
Temperature measurement range
|
0.0000 ℃ -40.000 ℃
|
|
Resolution
|
0.0001 ℃
|
|
Measurement accuracy
|
better than the national standard GB/T213-2008
|
|
Operating environment
|
Room temperature 5-40 ℃ (each measurement of room temperature change should be ≤ 1 ℃), relative humidity ≤ 85%
|
|
Power supply
|
220V ± 10% 50Hz
|
|
Instrument power
|
40W
|
