Technical characteristics of incinerator KTL series waste incinerator adopts the most advanced incineration method of primary pyrolysis gasification + ambient air mixed combustion + secondary incineration + burnout treatment. The design of the primary combustion chamber of the incinerator adopts gasification incineration technology, so that the temperature in the incinerator can be moved from 200 ° C to 400 ° C, so that the garbage will not have problems such as frit, slag, and sintering during the incineration process, and the amount of dust generated is very small. .
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
KTL-50
-
Power:
-
0.25, 0.25 KW
-
Material:
-
Wooden box
-
Marketing Type:
-
New Product 2024
-
Weight (KG):
-
4000 kg
-
Name:
-
animal incinerator
-
Raw material:
-
Carbon steel corrosion
-
Fuel:
-
Diesel/Natural Gas/LPG
-
Certification:
-
CE ISO
-
Advantage:
-
High Efficiecny
-
Voltage:
-
220V
-
Final product:
-
Ashes
-
Size:
-
1460*1000*2590mm
-
Feature:
-
No pollution
Quick Details
-
Production Capacity:
-
30-50kg/batch
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
KTL
-
Model Number:
-
KTL-50
-
Power:
-
0.25, 0.25 KW
-
Material:
-
Wooden box
-
Marketing Type:
-
New Product 2024
-
Weight (KG):
-
4000 kg
-
Name:
-
animal incinerator
-
Raw material:
-
Carbon steel corrosion
-
Fuel:
-
Diesel/Natural Gas/LPG
-
Certification:
-
CE ISO
-
Advantage:
-
High Efficiecny
-
Voltage:
-
220V
-
Final product:
-
Ashes
-
Size:
-
1460*1000*2590mm
-
Feature:
-
No pollution
Equipment Overview
Product Specifications
|
Type
|
Burning ability
（Kg/Batch）
|
Size(mm)
|
Chimney
|
Total Power
(KW)
|
Voltage(V)
|
Weight (KG)
|
|
KTI-30
|
20-30
|
L:1300
W:800
H:2300
|
OD219
|
0.55
|
220
|
2000
|
|
KTL-50
|
30-50
|
L:1460
W:1000
H:2590
|
OD280
|
0.55
|
220
|
2300
|
|
KTL-100
|
50-100
|
L:1700
W:1150
H:3000
|
OD280
|
0.55
|
220
|
4000
|
|
KTL-150
|
100-150
|
L:1800
W:1300
H:3200
|
OD280
|
0.55
|
220
|
5500
|
|
KTL-200
|
150-200
|
L:1900
W:1400
H:3500
|
OD300
|
0.8
|
220
|
7000
|
|
KTL-300
|
200-300
|
L:2100
W:1550
H:3800
|
OD400
|
0.98
|
220
|
8000
|
|
KTL-400
|
300-400
|
L:2600
W:1750
H:4270
|
OD400
|
1.05
|
220
|
11000
|
|
KTL-500
|
400-500
|
L:3000
W:2000
H:4800
|
OD500
|
1.05
|
220
|
13000
|
Equipment Advantages
1. It is easier to operate than the incinerators of other manufacturers. There is an automatic blower inside the burner to protect the burner and no operation is required. When you turn off the burner, the blower will automatically stop for a certain period of time.
2. Low operation and maintenance cost. The first burner is longer than the normal burner and is specially made to save fuel.
3. Environmental protection, duel room design, smokeless, odorless and pollution-free after waste incineration.
4. The maximum temperature can reach 1100-1300 degrees Celsius, which can achieve the effect of sterilization and disinfection.
5. Long service life. Materials of Construction - Heavy Duty Steel, Insulated and Refractory Lined Chambers.
6. Portable, small footprint.
7. The animal incinerator adopts automatic push-pull cart.
Our service
1. Recommend equipment suitable for customers.
2. Check the factory and provide inspection reception.
3. Provide sample test and demonstration operation.
Customer site visit
Company introduction
Shandong Kangtailong Intelligent Equipment Co., Ltd. is a modern enterprise focusing on the production and manufacturing of all kinds of waste incineration equipment.The company is located in Zhucheng, Shandong Province. Our company mainly produces all kinds of waste incinerator equipment, focusing on the solution of municipal solid waste, waste produced by the medical industry to sick and dead animals, industrial waste and other various types of waste produced in all walks of life.The product adopts the principle of thermal incineration of organic waste gas, which decomposes organic matter into inorganic matter and achieves standard discharge of flue gas.
For a long time, the company always adhere to the "science and technology for development, quality for survival" policy, to "pay close attention to quality for credibility, strengthen management for the upper echelon" as the goal, forge ahead, and strive to open up the market.All the employees of the company are willing to excellent products, good service, sincere attitude, and sincerely hope to cooperate with new and old friends closely, hand in hand to forge ahead, a total of grand exhibition.
