Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Specification:
-
Normal
-
Mounting Type::
-
Solar Ground Mounting System
-
Panel Inclination::
-
From 0 to 60 degree
-
Material::
-
Aluminum Alloy, Stainless Steel
-
Color::
-
Natural/Black
-
Warranty::
-
10 Years
-
Installation Site::
-
Ground
-
Load Power (W):
-
10KW
-
Output Voltage (V):
-
110V/220V
Quick Details
-
Color:
-
can do black
-
Brand Name:
-
SOLAR MASTER
-
Model Number:
-
400W 500W 550W
-
Place of Origin:
-
Jiangsu, China
-
Specification:
-
Normal
-
Mounting Type::
-
Solar Ground Mounting System
-
Panel Inclination::
-
From 0 to 60 degree
-
Material::
-
Aluminum Alloy, Stainless Steel
-
Color::
-
Natural/Black
-
Warranty::
-
10 Years
-
Installation Site::
-
Ground
-
Load Power (W):
-
10KW
-
Output Voltage (V):
-
110V/220V
Product Description
|
ENQUIRY US! SOLAR PANEL Poly 72 Whole cells
|
|
|
|
|
|
|||||
|
Moduel
|
SMT- 72-330P
|
SMT-72-335P
|
SMT-72-340P
|
SMT-72-345P
|
SMT-72-350P
|
|||||
|
Maximum Power at STC (Pmax)
|
330W
|
335W
|
340W
|
345W
|
350W
|
|||||
|
Optimum Operating Voltage (Vmp)
|
37.7 V
|
38.0 V
|
38.1V
|
38.2 V
|
38.4 V
|
|||||
|
Optimum Operating Current (Imp)
|
8.76A
|
8.82A
|
8.93A
|
9.04A
|
9.12A
|
|||||
|
Open Circuit Voltage(Voc)
|
45.8V
|
46.1V
|
46.5V
|
46.7V
|
46.9V
|
|||||
|
Short Circuit Current(Isc)
|
9.22A
|
9.3A
|
9.40A
|
9.50A
|
9.59A
|
|||||
|
Module Efficiency
|
17%
|
17.2%
|
17.5%
|
17.7%
|
18%
|
|||||
|
Operating Module Temperature
|
-40 °C to +85 °C
|
|
|
|
|
|||||
|
Maximum System Voltage
|
1000/1500 V DC (IEC)
|
|
|
|
|
|||||
|
Maximum Series Fuse Rating
|
20 A
|
|
|
|
|
|||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
|||||
|
Standard Test Condition(STC)
|
lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.
|
|
|
|
|
|||||
|
Mono Solar Panel 72 Whole cells
|
|
|
|
|||
|
Moduel
|
SMT-72-365M
|
SMT-72-370M
|
SMT-72-375M
|
|||
|
Maximum Power at STC (Pmax)
|
365W
|
370 W
|
375W
|
|||
|
Optimum Operating Voltage (Vmp)
|
39.5 V
|
39.7 V
|
39.9 V
|
|||
|
Optimum Operating Current (Imp)
|
9.24 A
|
9.32 A
|
9.40 A
|
|||
|
Open Circuit Voltage(Voc)
|
47.9 V
|
48.1 V
|
48.3 V
|
|||
|
Short Circuit Current(Isc)
|
9.71 A
|
9.78 A
|
9.85 A
|
|||
|
Module Efficiency
|
18.8%
|
19.0%
|
19.3%
|
|||
|
Operating Module Temperature
|
-40 °C to +85 °C
|
|
|
|||
|
Maximum System Voltage
|
1000/1500 V DC (IEC)
|
|
|
|||
|
Maximum Series Fuse Rating
|
20 A
|
|
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
Standard Test Condition(STC)
|
lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.
|
|
|
|||
|
Poly Solar Panel 60 Whole cells
|
|
|
|
|||
|
Moduel
|
SMT-60-275P
|
SMT-60-280P
|
SMT-60-285P
|
|||
|
Maximum Power at STC (Pmax)
|
275W
|
280W
|
285W
|
|||
|
Optimum Operating Voltage (Vmp)
|
31.4V
|
31.6 V
|
31.7 V
|
|||
|
Optimum Operating Current (Imp)
|
8.76 A
|
8.86 A
|
9.00 A
|
|||
|
Open Circuit Voltage(Voc)
|
38.1V
|
38.5 V
|
38.9 V
|
|||
|
Short Circuit Current(Isc)
|
9.27A
|
9.38 A
|
9.46A
|
|||
|
Module Efficiency
|
16.8%
|
17.1%
|
17.4%
|
|||
|
Operating Module Temperature
|
-40 °C to +85 °C
|
|
|
|||
|
Maximum System Voltage
|
1000/1500 V DC (IEC)
|
|
|
|||
|
Maximum Series Fuse Rating
|
20 A
|
|
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
Standard Test Condition(STC)
|
lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.
|
|
|
|||
|
Mono Solar Panel 60 Whole cells
|
|
|
|
|||
|
Moduel
|
SMT-60-305M
|
SMT-60-310M
|
SMT-60-315M
|
|||
|
Maximum Power at STC (Pmax)
|
305W
|
310W
|
315W
|
|||
|
Optimum Operating Voltage (Vmp)
|
32.8V
|
33.1 V
|
33.4 V
|
|||
|
Optimum Operating Current (Imp)
|
9.3 A
|
9.37 A
|
9.43 A
|
|||
|
Open Circuit Voltage(Voc)
|
39.8V
|
40.2 V
|
40.6V
|
|||
|
Short Circuit Current(Isc)
|
9.8A
|
9.87A
|
9.92A
|
|||
|
Module Efficiency
|
18.6%
|
18.9%
|
19.2%
|
|||
|
Operating Module Temperature
|
-40 °C to +85 °C
|
|
|
|||
|
Maximum System Voltage
|
1000/1500 V DC (IEC)
|
|
|
|||
|
Maximum Series Fuse Rating
|
20 A
|
|
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
Standard Test Condition(STC)
|
lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.
|
|
|
|||
Residential
Commercial
Industrial
Components
SOLAR PANEL
Monocrystalline, Polycrystalline and BIPV
White or Black Panels
Half cut / Square Mono / 12BB/ MWT
IEC, TUV, CE, ISO
MOUNTING SYSTEM
Pitched roof, flat roof, pole mount, ground mount
A variety of different roof connectors and zero
penetration ballast steel or Aluminum Alloy
Material: Aluminum Alloy or galvanized steel
INVERTER
Monitoring options allow for better performance
collection and project oversight
Dual MPPT technology provides numerous layout
On-Grid, Off-Grid, Hybrid
BOS COMPONENTS
AC/DC disconnects, wiring harnesses, MC4 connectors,
wire, safety label packs, MC4 connector tools
Grounding hardware, PV tools
BATTERY
Battery monitoring including current, voltage,
and temperature,
Modular design allows for future energy storage
add-ons.
Monitoring System
Free online monitoring via phone App or desktop
WI-FI or GPRS technology data logging functionality
Download and view generation statistics offline
