Quick Details
-
Brand Name:
-
SZ
-
Model Number:
-
Drywall screw machine
-
Weight (KG):
-
300
-
Power (kW):
-
2.2
-
Product name:
-
Cold heading machine to make drywall
-
The Max.length:
-
20mm/40mm/60mm/80mm/90mm
-
Max.diameter:
-
4.0mm/5.0mm/7.0mm/7.0mm/9.0mm
-
Type:
-
Thread rolling machine for screw
-
Weight:
-
624kg/1105kg/2080kg/2340kg/3640kg
-
After-sales Service:
-
Forever
-
After-sales Service Provided:
-
Free spare parts, Online support, Video technical support, Field maintenance and repair service
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
None
Quick Details
-
Wire Diameter (mm):
-
20 - 120 mm
-
Production Capacity:
-
70-140times/min
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
SZ
-
Model Number:
-
Drywall screw machine
-
Weight (KG):
-
300
-
Power (kW):
-
2.2
-
Product name:
-
Cold heading machine to make drywall
-
The Max.length:
-
20mm/40mm/60mm/80mm/90mm
-
Max.diameter:
-
4.0mm/5.0mm/7.0mm/7.0mm/9.0mm
-
Type:
-
Thread rolling machine for screw
-
Weight:
-
624kg/1105kg/2080kg/2340kg/3640kg
-
After-sales Service:
-
Forever
-
After-sales Service Provided:
-
Free spare parts, Online support, Video technical support, Field maintenance and repair service
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
None
Drywall nail machine: It is composed of cold heading machine and thread rolling machine.
Cold heading machine is a special equipment mainly used for mass production of nuts and bolts and other fasteners. Features:
The connections between the crankshaft and the body and the impact connecting rod are all connected by high wear-resistant alloy copper tiles, which have large bearing capacity, long service life and low maintenance costs.
The machine body is cast by adding alloyed ductile iron 500, with high tensile strength and good wear resistance.
Thread rolling machine is an equipment specializing in the production of screws. The definition thread rolling machine is a professional equipment for the production of screws. The thread rolling machine is light, flexible, efficient and has the advantages that other similar equipment cannot replace. The thread rolling machine avoids the limitations of lathes, drilling machines or manual tapping, saving time, labor, not easy to rot, and the taps are not easy to break.
|
Max.diameter |
4.0 mm |
5.0 mm |
7.0 mm |
7.0 mm |
9.0 mm |
|
The Max.length |
20 mm |
40 mm |
60 mm |
80 mm |
90 mm |
|
Capacity |
1 2 0-1 4 0 pcs/min |
10 0-1 2 0pcs/min |
9 0- 10 0 pcs/min |
9 0- 10 0 pcs/min |
70-90 pcs/min |
|
main die diamete |
φ20*36 mm |
φ32*60 mm |
φ40*80 mm |
φ40*100 mm |
φ45*120 mm |
|
The motor power |
1.1KW |
1.5KW |
2.2KW |
2.2KW |
4.0KW |
|
Size (L*/W*H) |
140*75*79 mm |
175*85*115 mm |
230*108*125 mm |
230*108*125 mm |
270*140*160 mm |
|
Weight |
624 kg |
1105 kg |
2080 kg |
2340 kg |
3640 kg |
