Quick Details
-
Brand Name:
-
SYBX
-
Standard or Nonstandard:
-
Standard
-
Quality Control:
-
ISO9001:2008
-
Colder outlet:
-
not above 49
-
Hotter outlet:
-
not below 54
-
Two way outlet:
-
between49--54
-
Material:
-
Brass with nickel plated
-
Usage:
-
Water heater system
-
Connection:
-
BSP,3/4"
-
Thread:
-
Male
-
Port:
-
One inlet with two outlets
Quick Details
-
Port Size:
-
DN20
-
Place of Origin:
-
Liaoning, China
-
Model Number:
-
BXHX20
-
Brand Name:
-
SYBX
-
Standard or Nonstandard:
-
Standard
-
Quality Control:
-
ISO9001:2008
-
Colder outlet:
-
not above 49
-
Hotter outlet:
-
not below 54
-
Two way outlet:
-
between49--54
-
Material:
-
Brass with nickel plated
-
Usage:
-
Water heater system
-
Connection:
-
BSP,3/4"
-
Thread:
-
Male
-
Port:
-
One inlet with two outlets
|
Model:BXHX20 SELECTOR VALVE (DIVERTER VALVE) WITHOUT CHECK VALVE |
|
|
Body |
Brass with nickel plated |
|
Temperature setting range |
40-45 ºC |
|
Hot and Cold water inlet temperature range |
4-95 ℃ |
|
Maximum working temperature |
≤99 ºC |
|
Temperature stability |
+/-2 ºC |
|
Working pressure |
0.03-1Mpa |
|
Ideal working pressure |
0.1-0.5Mpa |
|
Connections |
G 3/4", Inlets: M, Outlet: M |
|
Flow rate(1 kg pressure drop) |
26.67 L/min |
|
Three way valves |
Two outlets , one inlet |
|
Net weight |
0.494 KGS |
|
Gross weight |
0.554 KGS |
1. Technical Data
BXHX 20 G3/4”
a. Maximum working temperature: 99 C
b. Rated outlet flow on 1 bar pressure drop:26.67L/Min
2. Materials of Construction
a. Valve body: Nickel plated brass
b. Shutter: PPO
c. Connection: Inlets-M ale thread , outlet-M ale thread
3. Usage of Selector valves
Point of use mixing for wash hand basins, bidets, baths and showers in hospitals, schools, sport and leisure facilities, prisons and other public buildings.
4.How they work ?
Temperature range: 40-45 ℃
When coming water is below 40 ℃ , it will flow out from cold port. When above 45 ℃ , flow from hot port. When the temperature between 40-45 ℃ , it will flow from both ports.
Normally it is applied in solar heater and gas/electric water heater system. When sun shine is short and water temp from solar geyser is not hot enough, the water will be flow into for the secondary heating, such as gas or electric heater for second heating.
