Quick Details
-
Production Capacity:
-
220bag/min
-
Voltage:
-
220V/380V 50/60Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SanPong
-
Dimension(L*W*H):
-
3900mm*950mm*1500mm
-
Product name:
-
Pack Wrapping Machine
-
Measuring device:
-
3900mm*950mm*1500mm
-
Sealing speed:
-
20-220 bags/min
-
Material:
-
carbon steel frame
-
Sealing way:
-
3/4Sides sealing,back sealing
-
Bagging material:
-
OPP,OPP/PE,OPP/CPP
-
Film Width:
-
max 220mm
-
Bag widt:
-
30-90mm
-
Bag length:
-
60-1000mm
-
Certification:
-
CE certification
Quick Details
-
Function:
-
FILLING, Wrapping, Labeling, Sealing, SLITTING
-
Packaging Type:
-
Stand-up Pouch, Bags, Film, Pouch
-
Packaging Material:
-
Plastic, Paper, Metal
-
Production Capacity:
-
220bag/min
-
Voltage:
-
220V/380V 50/60Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SanPong
-
Dimension(L*W*H):
-
3900mm*950mm*1500mm
-
Product name:
-
Pack Wrapping Machine
-
Measuring device:
-
3900mm*950mm*1500mm
-
Sealing speed:
-
20-220 bags/min
-
Material:
-
carbon steel frame
-
Sealing way:
-
3/4Sides sealing,back sealing
-
Bagging material:
-
OPP,OPP/PE,OPP/CPP
-
Film Width:
-
max 220mm
-
Bag widt:
-
30-90mm
-
Bag length:
-
60-1000mm
-
Certification:
-
CE certification

Product Application
High speed pillow shape plastic bag packing sleeping bag with pillow packing machine pe pillow bag packaging machine is suitable for producing pouch in various shape. It is widely used to produce the powder,granule packaging etc.
SPECIFICATIONS
|
|
|
|
Model
|
X-DZJ
|
Film width
|
max:220mm
|
Bag length
|
60-1000mm
|
Bag width
|
30-90mm
|
Bag height
|
5-35mm
|
Film roll diameter
|
max:300mm
|
Speed
|
20-220 bags/min
|
Bagging material
|
OPP,OPP/PE,OPP/CPP
|
Power
|
220V, 50/60HZ, 2.9KW
|
Machine size
|
(L)4115*(W)830*(H)1400mm
|
Machine weight
|
450KG
|



Main Features
1.Servo control,instant bag size control and cutting,no need to waste film.
2. Coloured touch screen control,easy parameter setting,it cans save 40 different parameter datas.
3. Malfunction self-check system,it is easy to check error.
4.High sensitivity photoelectric colour batch checking.it uses digital input to set cutting position,which is more accurate.
5.Individual temperature PID control,makes it more applicable for more packing material.
6. Positioned stop system,avoids bonding with knife and waste of film.
7.Driving system is clear,running is reliable,maintanence is convinient.
8.When it cuts product accidentally it will rotate automatically,a restart of machine will keep the machine runs.
9.When the film runs out,the machine will stop.
10. For certain needs,it can fullfill automactically product length check and packing film length change,no need to set any parameter.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory and showroom is welcome.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packaging
|
|
|
Size
|
(L)4115*(W)830*(H)1400mm
|
|
Weight
|
195KG
|
|
Packaging Details
|
The normal package is wooden box(Size:(L)4115*(W)830*(H)1400mm). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
|
FAQ
Q1: How to find a Packing machine suitable for my product?
Tell us about your product details and packing requirements.
1. What kind of product you would liek to pack?
2. The bag/sachet/pouch size of you need for the product packing ( the length, width).
3. The weigh of each pack you need.
4. You requirement for the machines and the bag style.
Q2: Is engineer available to serve oversea?
Yes, but the travel fee is responsible by you.
In order to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q3. How can we make sure about the machine quality after placking the order?
Before delivery, we will send you the pictures and videos for you to check the machine quality.
And also you can arrange for quality checking by yourself or by your contacts in China.
Q4. We are afraid you won't send us the machine after we send you the money?
We have our business license and certificate. And it is available for us to use alibaba trade assurance service,guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q5. Can you explain me the whole transaction process ?
1.Sign the Contact
2.Arrange 30% deposit to our factory
3.Factory arrange production
4.Testing & detecting the machine before shipping
5.Inspected by customer or third agency through online or site test.
6.Arrange the balance payment before shipment.
Q6: Will you provides the delivery service?
A: Yes. Please inform us of your final destination, we will check with our shipping agent to quote the shipping cost for your reference before delivery.
