- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
HD10NW64
-
Dimension:
-
10inch
-
Power Supply Mode:
-
Other
-
Nominal diameter:
-
250/10mm/inch
-
Rated impedance:
-
8ohm
-
Nominal power (AES):
-
300W
-
Maximum power:
-
600W
-
Sensitivity (1w/1m):
-
96dB
-
Frequency response:
-
67-3.5KHz
-
Voice coil diameter:
-
64/2.5mm/ inch
-
Magnet Type:
-
Neodymium
-
Magnet size:
-
64mm
-
Fs:
-
68Hz
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HD
-
Model Number:
-
HD10NW64
-
Dimension:
-
10inch
-
Power Supply Mode:
-
Other
-
Nominal diameter:
-
250/10mm/inch
-
Rated impedance:
-
8ohm
-
Nominal power (AES):
-
300W
-
Maximum power:
-
600W
-
Sensitivity (1w/1m):
-
96dB
-
Frequency response:
-
67-3.5KHz
-
Voice coil diameter:
-
64/2.5mm/ inch
-
Magnet Type:
-
Neodymium
-
Magnet size:
-
64mm
-
Fs:
-
68Hz
Why choose us
1: We are speaker manufacturer, our factory is over 2400 Square maters .
2. We have our engineer team, and our boss is the chief engineer who has engaged in speaker development for over 20 years.
3. .We accept low MOQ, MOQ:2-10 pcs .
5. After sale service: One year warranty or 3% spare recone kit .
6 We provide OEM and ODM service.
| Specification | ||
| Nominal diameter | 250/10 | mm/inch |
| Rated impedance | 8 | ohm |
| Nominal power (AES) | 300 | W |
| Maximum power | 600 | W |
| Sensitivity (1w/1m) | 96 | dB |
| Frequency response | 67-3.5K | Hz |
| Voice coil diameter | 64/2.5 | mm/ inch |
| Magnet Type | Neodymium | |
| Magnet size | 64 | mm |
| T/S Parameter | ||
| Fs | 68 | Hz |
| Re | 5.3 | Ω |
| Qes | 0.44 | |
| Qts | 0.4 | |
| Qms | 4.7 | |
| Vas | 26 | L |
| Cms | 0.15 | mm/N |
| Mms | 35 | gr |
| BL | 13.5 | N/A |
| Le | 0.6 | mH |
| Mounting information | ||
| Overall diameter | 261 | mm |
| Bolt Circle diameter | 245 | mm |
| Baffle Cutout diameter | 230 | mm |
| Depth | 114 | mm |
| Net weight | 3 | KG |
| Shipping (1 inc 1) | 280*280*150 | mm |
Features
--600 W continuous program power capacity
--64 mm (2.5 in) copper voice coil
--60-2500 Hz response
--96 dB sensitivity
--Neodymium magnet allows a very light yet powerful motor assembly
--Shorting copper cap for extended HF response
--Ventilated voice coil gap for reduced power compression
