Quick Details
-
Brand Name:
-
9000 series
-
Model Number:
-
N9K-C9336C-FX2, N9K-C9336C-FX2
-
Place of Origin:
-
Beijing, China
-
System memory:
-
24 GB
-
Dimensions (H x W x D):
-
1.72 x 17.3 x 22.5 in.
-
Warranty:
-
1 Year
-
Frequency:
-
50 to 60 Hz
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex
-
Switch Capacity:
-
24 GB
-
Brand Name:
-
9000 series
-
Model Number:
-
N9K-C9336C-FX2, N9K-C9336C-FX2
-
Place of Origin:
-
Beijing, China
-
System memory:
-
24 GB
-
Dimensions (H x W x D):
-
1.72 x 17.3 x 22.5 in.
-
Warranty:
-
1 Year
-
Frequency:
-
50 to 60 Hz
9000 series gigabit ethernet core switch N9K-C9336C-FX2
|
Models |
N9K-C9336C-FX2 |
N9K-C9336C-FX2-E |
|||
|
Ports |
36 x 40/100-Gbps QSFP28 ports |
36 x 40/100-Gbps QSFP28 ports |
48 x 1/10/25-Gbps and 12 x 40/100-Gbps QSFP28 ports |
96 x 1/10/25-Gbps and 12 x 40/100-Gbps QSFP28 ports |
96 x 100M/1/10GBASE-T ports and 12 x 40/100-Gbps QSFP28 ports |
|
Supported speeds |
1/10/25/40/100-Gbps Ethernet Breakout supported on all ports, 1-36: 100G, 2x50G NRZ, 40G native, 4x10/25G (10G w/QSA) 1G w/QSA except ports 1-6 and 33-36 |
1/10/25/40/100-Gbps Ethernet Breakout supported on all ports, 1-36: 100G, 2x50G NRZ, 40G native, 4x10/25G (10G w/QSA) 1G w/QSA except ports 1-6 and 33-36 16/32-Gbps Fibre Channel |
1/10/25-Gbps on downlinks 40/100-Gbps on uplinks |
1/10/25-Gbps on downlinks 40/100-Gbps on uplinks Breakout supported ports, 97-108: 4x10/25G |
100M/1/10 Gbps RJ45 downlinks 40/100-Gbps on uplinks Breakout supported ports, 97-108: 4x10/25G |
|
CPU |
4 cores |
4 cores |
4 cores |
4 cores |
4 cores |
|
System memory |
24 GB |
24 GB |
Up to 24 GB |
Up to 24 GB |
Up to 24 GB |
|
SSD drive |
128 GB |
128 GB |
128 GB |
128 GB |
128 GB |
|
System buffer |
40 MB |
40 MB |
40 MB |
40 MB |
40 MB |
|
Power supplies
|
750W AC * , 1100W AC, 1100W DC, 1100W HVAC/HVDC |
750W AC, 1100W AC, 1100W DC, 1100W HVAC/HVDC ** |
750W AC * , 1100W AC, 1100W DC, 1100W HVAC/HVDC |
1200W AC, 1200W HVAC/HVDC |
1200W AC, 1200W HVAC/HVDC |
|
Typical power (AC) |
337W |
337W |
298W |
404W |
580W |
|
Maximum power (AC) |
719W |
705W |
708W |
900W |
965W |
|
Fans |
3 dual fan trays |
6 |
5 |
3 fan trays |
3 fan trays |
|
Physical dimensions
|
1.72 x 17.3 x 24.5 in. (4.4 x 43.9 x 62.3 cm) |
1.72 x 17.3 x 24.7 in. (4.4 x 43.9 x 62.7 cm) |
2.1 x 17.3 x 23.3 in. (5.3 x 43.9 x 59.1 cm) |
3.38 x 17.41 x 24.14in. (8.59 x 44.23 x 61.31 cm) |
3.38 x 17.41 x 23.6 in (8.59 x 44.2 x 59.9 cm) |
