Quick Details
-
Application:
-
Warehouse
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Tailai
-
Model Number:
-
Steel Structure
-
Name:
-
Steel Structure Building
-
main frame:
-
columns and beams
-
Insulation material:
-
sandwich panel or steel sheet
-
Wall and Roof:
-
color steel board or sandwich panels
-
Window:
-
Aluminium Alloy Window
-
Door:
-
Auto Rolling Shutter
-
Color:
-
Blue/Red/Gray or as your require
-
certification:
-
ISO9001
-
Size:
-
as your require
Quick Details
-
Type:
-
steel workshop building, Light Steel Struture
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Warehouse
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Tailai
-
Model Number:
-
Steel Structure
-
Name:
-
Steel Structure Building
-
main frame:
-
columns and beams
-
Insulation material:
-
sandwich panel or steel sheet
-
Wall and Roof:
-
color steel board or sandwich panels
-
Window:
-
Aluminium Alloy Window
-
Door:
-
Auto Rolling Shutter
-
Color:
-
Blue/Red/Gray or as your require
-
certification:
-
ISO9001
-
Size:
-
as your require
Product Application
Steel structure building is formed by the main framework through linking up the H beam, C purline, Z purline steel components. Roof and wall using a variety of panels together with other components such as windows and doors. The steel building has the advantages of wide span, high strength, light weight, low cost, temperature protection, save energy, beautiful appearance, short construction time, good effect of insulation, long using life, space-efficient, good seismic performance, flexible layout, etc.
|
SPECIFICATIONS FOR STEEL STRUCTURE BUILDING
|
|
|
|
|||
|
|
Item
|
Material
|
Description
and surface process
|
|||
|
Main steel frame
|
Column and Beam
|
Q235 or Q345
|
H section steel with two coats of mid-gray paint
|
|||
|
|
Purlin
|
Q235 or Q345
|
Galvanizd C or Z type steel
|
|||
|
Connecting Pieces |
Tie tube
|
Q235
|
Circular Tube with two coats of mid-gray paint
|
|||
|
|
Knee-Bracing
|
Q235
|
L50*4 Galvanizd angle steel
|
|||
|
|
Strutting piece
|
Q235
|
φ12 Galvanizd Circular steel
|
|||
|
|
Column Bracing
|
Q235
|
Circular Tube with two coats of mid-gray paint
|
|||
|
|
Horizontal Bracing
|
Q235
|
Circular Tube with two coats of mid-gray paint
|
|||
|
|
Casing
|
Q235
|
φ30*2.5 Galvanized Circular Tube
|
|||
|
Door and Window
|
Item
|
Description
|
|
|||
|
|
Door
|
Roller shutter door or Sliding door
|
|
|||
|
|
Window
|
PVC Window or aluminum alloy window
|
|
|||
|
Other parts
|
Ventilating device
|
Fan,Ventilation window
|
|
|||
|
|
Bolt
|
Foundation bolt,High strengthen bolt, Normal bolts
|
|
|||
|
|
Skylight
|
Yx-840 Glass Fiber Reinforced Plastics
|
|
|||
|
|
Out/Inner ridge tile
|
0.50mm Color sheet
|
|
|||
|
|
Crane beam
|
Q235 or Q345 H section steel with two coats of mid-gray paint
|
|
|||
Main Features
1)Enviromental friendly
2) Lower cost and maintenance
3) Long using time up to 50 years
4) Stable and earthquake resistance up to 9 grade
5) Fast construction, time saving and labor saving
6) Good appearance
Established in year 2003, Weifang Tailai Steel Structure Engineering Co., Ltd, with registered capital 16 million RMB, located in Dongcheng Development district, Linqu County,Taila is one of the largest steel structure related produsts manufacturer in China, specializes in construction design, manufacturing, instruction project construction, steel structure material and so on ,has the most advanced product line for H section beam, box column, truss frame, steel grid, light steel keel structure. Tailai also has the high precision 3-D CNC drilling machine, Z & C type purlin machine, multi-model color steel tile machine, floor deck machine, and fully equipped inspection line.
1.Cutting
2.Assembling
Use H Beam Assembling Machine
3.Submerged arc welding
Use H-Beam Welding Machine
4.Straightening
Use Vertical Straightening Machine
5. Welding
Use Carbon Dioxide arc welding
6.Ultrasonic flaw detection
Use Ultrasonic flaw detector
7.Shot blasting
Use H sectiong steel shot blasting derusing machine
8.Painting
Use High-pressure airless spraying
9.Finished
One coat of iron red primer, two coats of finished paint
|
Packaging
|
|
|
|
Size
|
11.8(L) * 2.13 (W) * 2.72 (H)
|
|
|
Weight
|
24T
|
|
|
Packaging Details
|
all of the steel structure columns and the beams ends will be packed by the blanket to protect them from the collision during the shipping in the container.
|
|
|
Packaging
|
|
|
|
Size
|
11.8(L) * 2.13 (W) * 2.72 (H)
|
|
|
Weight
|
24T
|
|
|
Packaging Details
|
all of the purlin ends will be packed by the blanket to protect them from the collision during the shipping in the container.
|
|
Q1:Are you manufacturer or trade company?
We are professional manufacturer of steel structure building.
Q2:Are steel structure buildings expensive?
The steel structure of Weifang Tailai company is economic. Its technology and materials used decreases cost of the building . All the material including the steel frames, wall body and roof for installation are prefabricated during the production process, therefore the labor costs for installation is decreased.
Q
3:What if I have questions during the installation of my building?
we can send our engineer to your country to guide the workers, or we also have professional service team ,they will help you install the steel structure building .
Q4: Is there any warranty available on the steel structure buildings?
The steel structure buildings have limited warranty. Usually, we build the house complied with the GB Chinese standard
1. We would offer you the most valuable quotation,if you provide us with the following information.
2) Doors and windows: Dimension, quantity, position to put them.
3)Local climate: Wind speed, snow load, etc.
4) Insulation material: Sandwich panel or steel sheet.
5)Crane beam: Do you need crane beam inside the steel structure? And its capacity.
6) If other requirements, such as fire proofing, isolated roof, etc, please kindly inform us.
