Quick Details
-
Place of Origin:
-
China,Dongguan
-
Brand Name:
-
Do Hearts
-
Dimensions(L*W*H):
-
13m*0.6m*1.5m
-
Weight:
-
2000 KG
-
Certification:
-
CE
-
Application:
-
Textiles Printing
-
Type:
-
Silk Screen Printing Machine
-
Printing color:
-
2/3/4
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
None
-
Showroom Location:
-
None
-
Marketing Type:
-
New Product 2020
Quick Details
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Voltage:
-
380V
-
Place of Origin:
-
China,Dongguan
-
Brand Name:
-
Do Hearts
-
Dimensions(L*W*H):
-
13m*0.6m*1.5m
-
Weight:
-
2000 KG
-
Certification:
-
CE
-
Application:
-
Textiles Printing
-
Type:
-
Silk Screen Printing Machine
-
Printing color:
-
2/3/4
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
None
-
Showroom Location:
-
None
-
Marketing Type:
-
New Product 2020
fully auto infrared heating type satin ribbons elastic silk screen printing machine
Automatic 3d silicone silk screen Printing machine:
1-4color avaiable
Automatic operation
PLC control
Patented machinery
This silk screen printing machine for woven tapes and fabric can print up 2-4 colors silicone logo or figures or letters onto on fabric, woven tapes,webbing,belts laces, underwear, mesh and some others tapes. Are mainly used in underwear, woven webbing, hangtag tape and more.
Automatic 3D silicone screen printing machine details:
Features:
Automatic silicone 3D printer machine,2-4color avaiable.
the width of tap is between min 3mm to max 260mm.
Use electrical photo-cell tracing to positioning, acurate and precise.
1-5tapes can be processed at one time.
Running speed and oven tempertaure adjustable, to meet different requirement.
| Model | DH-PM02-1 | DH-PM02-2 | DH-PM02-3 | Remark |
| Halftone | 1 | 2 | 3 | |
| Printing color | 1 | 2 | 3 | |
| Conveyor belt width | 300mm | |||
| positioning | Electrical photo-cell tracing | |||
| Min.tape width | 3mm | |||
| Max.tape width | 260mm | |||
| Max.printing area | L500*W260 |
Printing length
determines speed |
||
| Running speed | 600-1800time/h | 800-2600time/h | 1000-3200time/h | |
| Oven Temperature | 50-200℃ |
Printing material
determines temperature |
||
| Measurement | L11500*W550*H1850 | L15500*W550*H1850 | L19500*W550*H1850 | |
| Weight | 1000kg | 1500kg | 2000kg | |
| Air requirement | 6kg/cm2 | |||
| Electrical requirement | 6-12KW/380V AC | 6-24KW/380V AC | 8-24KW/380V AC |
Printing material
determines temperature |
Automatic Silicone 3D Printing Machine Samples:
Pre-sale service:
1.You will get free solution for your production with suitable machinery combination
2. You will get Factory direct sale price.
3. You will get durable quality of machine and most professional service.
4. Your visiting to our factory for checking or training is warmly welcome.
After-sale service:
1. Warranty: 1 year free and life long maintenance
2. Free installation & training service.
3. 24 hours online consult a day;
