Quick Details
-
Thickness:
-
5mm 500mm
-
Size:
-
Maximum length: 2800mm . Maximum width: 1400mm
-
Application:
-
Pontoon Boat
-
Color:
-
Customized
-
Feature:
-
Lightweight & high-strength
-
Density:
-
120 kg/m³
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HolyCore
-
Thickness:
-
5mm 500mm
-
Size:
-
Maximum length: 2800mm . Maximum width: 1400mm
-
Application:
-
Pontoon Boat
-
Color:
-
Customized
-
Feature:
-
Lightweight & high-strength
-
Density:
-
120 kg/m³
Product Description
HolyPan is one of the lightest and strongest composite sandwich panels produced for industries.This innovative sandwich panel is thermally fused with polypropylene honeycomb core and fiberglass reinforced polypropylene skin.
The core material gives HolyPan high resistance due to its honeycomb structure, and the super strong fiberglass-reinforced skin materials provide high stiffness and an extremely good impact resistance of the panel surface. The thermally fused connection between the honeycomb core and the skins leads to an indivisible connection and makes HolyPan much lighter and eco friendly. And the delamination of the skin is almost impossible which distinguishes it from other traditionally glued or laminated panels.
Compared with other materials, the cost of HolyPan is much lower. Compared with plywood panels, HolyPan is much lighter. HolyPan could be used in different pontoon boat deck.
Specification
|
Physical Properties of HolyPan
|
|
|
|
|||
|
Test Items
|
Test Results
(25mm HolyPan)
|
Test Results
(30mm HolyPan)
|
Testing Standard
|
|||
|
Compressive Strength
|
2.0MPa
|
2.1MPa
|
ASTM C365
|
|||
|
Shear Strength
|
0.45MPa
|
0.55MPa
|
ASTM C273
|
|||
|
Shear Modulus
|
16.5MPa
|
20MPa
|
ASTM C273
|
|||
|
Peel Strength
|
145（N*mm)/mm
|
160（N*mm)/mm
|
ASTM D1781
|
|||
|
Bending Strength
(Load-bearing spacing 150mm)
|
8.6MPa
|
8.7MPa
|
ASTM C393
|
|||
|
Impact Strength
|
Height 359mm
|
Height 359mm
|
ASTM D5628-96
|
|||
Details and Advantages
Light weight and high strength
The honeycomb structure core material and fiberglass reinforced skin laminated through thermoplastic process high strength.
Durable and stable
Water and acid resistant, not easy to corrode and crack, can be used in a humid environment for a long time.
Environmentally friendly
Using 100% recyclable materials, healthy and non-toxic, can replace wood and save nature resources.
Easy to laminate
The smooth and flat polypropylene panel is easy to laminate and maintain, which can effectively save human costs and maintenance costs.
Great temperature suitability
The panel is stable in the temperature of -40℃ and 80℃, which is very safe and reliable.
For more product and service information, please contact us through the link below, and we’re looking forward to your inquiry!
Packing & Delivery
FAQ
1.Can the panels be cut to different sizes?
We can customize different sizes for you, but there will be some wastage.
2.How the panels are packed?
We will provide packaging solutions according to the size of the board, bulk or pallet.
3.What colors are the panels?
General colors are black and white, other colors need to be customized individually, and the MOQ is 3000㎡.
