Quick Details
-
Brand Name:
-
OEM
-
Power supply:
-
FTTH optical fiber mini node
-
F connector:
-
M/F
-
Wavelength:
-
1100~1600nm & 1550nm /1310nm
-
Input optical power:
-
0dBm~-7dBm(Analogy Signal)
-
Input optical power1:
-
0dB~-10dBm(Digital signal)
-
Optical connector:
-
FC/APC&SC/APC FC/PC&SC/PC
-
Bandwidth:
-
40~862MHz
-
Output port level:
-
>68dBuV(0dBm test)
-
Application:
-
FTTH FTTB FTTX Network
-
Size:
-
65x22x10mm
-
No. of Fiber:
-
1.
-
Use:
-
FTTH
Quick Details
-
Type:
-
Optical Fibers
-
Model Number:
-
optical catv receiver
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
OEM
-
Power supply:
-
FTTH optical fiber mini node
-
F connector:
-
M/F
-
Wavelength:
-
1100~1600nm & 1550nm /1310nm
-
Input optical power:
-
0dBm~-7dBm(Analogy Signal)
-
Input optical power1:
-
0dB~-10dBm(Digital signal)
-
Optical connector:
-
FC/APC&SC/APC FC/PC&SC/PC
-
Bandwidth:
-
40~862MHz
-
Output port level:
-
>68dBuV(0dBm test)
-
Application:
-
FTTH FTTB FTTX Network
-
Size:
-
65x22x10mm
-
No. of Fiber:
-
1.
-
Use:
-
FTTH
FTTH optical fiber mini node
FTTH optical fiber mini node is specially designed for FTTB - Fiber to the building network structure. Low consumption, high output level, small size, compact and reasonable internal circuit structure and excellent performance make it to be the first choice to build CATV FTTB network. Main used to fiber to building network to simple the network structure, reduce the cost and optimize the signal quality.
passive type, no need power support.
FTTH optical fiber mini node features f op tical catv receiver
1)High quality brushed aluminum case or plastic case.
2)Digital signal input -10dB, analog signal input -7dB.
3)Without power supply and consumption.
4)SC/APC or FC/APC.
5)Output level> 68dBuv (pin=0dB).
6)Micro FTTH optical CATV 1550 nm receiver node mini passive fiber optic node
|
Technical Data
|
FTTH optical fiber mini node
|
|
Wavelength
|
1100~1600nm&1550nm
|
|
Input optical power
|
0dBm~-7dBm(Analogy Signal) & 0dB~-10dBm(Digital signal)
|
|
Return loss
|
>45dB
|
|
Optical connector
|
FC/APC&SC/APC FC/PC&SC/PC
|
|
Bandwidth
|
40~862MHz
|
|
Flatness
|
±0.75dB@40~862 MHz & 1006MHz
|
|
RF output port level
|
≥16dB@40~550 MHz ≥14dB@550~862&1006MHz
|
|
Output port level
|
>68dBuV(0dBm test)
|
|
CNR(note1)
|
≥51dB
|
|
CTB(note1)
|
≥65dB
|
|
CSO(note1)
|
≥62dB
|
|
Working temperature
|
-25℃ ～+ 45℃
|
|
Output port
|
1
|
|
RF output impedance
|
75Ω
|
|
Size
|
65x22x10mm
|
passive type optical catv receiver
no need power support
small size and light weight
popular around the world
micro node FTTH receiver mini CATV 1550nm optical catv receiver
Welcome to our company!
Shanghai Yogel Communication Equipment Co., Ltd. is a professional company engaged in optical fiber passive devices, fusion splicer & accessories and optical test instruments. We provide sales and services of patch cords, fast connector, fiber coupler, optical adapters and fiber splice closure. Based on competitive prices, high-quality products and innovative technology, we stand apart from the rest in domestic FTTH, the DTV head-ends and broadcast industry.
Packing Details of optical catv receiver
soft packing in side, with inside protecting foam,1/ plastic bag, 1/ carton box.
Delivery Details
of optical catv receiver
3-7 days after receipt the payment
We offer the sincere dedicated service!
Before Sale
of
optical catv receiver
every product would be under quality control before send away, detailed products test report
related specifications
During Cooperation
for
optical catv receiver
OEM Service Offered, lable , packing
Design Service Offered, shape , color
Buyer Label Offered
After Sale
for
optical catv receiver
Any problems on the product, please contact us
warranty: 1~2 years
1,Can I get some samples of
FTTH mini CATV 1310nm 1550nm node optical CATV receiver
?
Yes, Sample order is available for quality check and market test .And for tiny order, you just to pay the express cost.
2. What’s delivery time of
optical catv receiver
?
It usually takes about 5-7 working days
3. What’s your payment terms ?
We usually accept all these kinds of payment terms .Such as T/T,L/C, Western Union.Cash Etc, optional
4. What’s your warranty terms ?
We offer 12 months warranty time .
