Quick Details
-
Power (kW):
-
7.5
-
Product name:
-
Dk77
-
Type:
-
Fast Wire Cutting
-
Application:
-
Moulds Machining
-
Max. cutting thickness(mm):
-
450mm
-
Working weight:
-
450kg
-
Precision:
-
0.01mm
-
Function:
-
Mould Processing
-
Payment:
-
LC Paypal Etc
-
Surface Roughness:
-
Ra<2.5um
-
Color:
-
Customers Optional
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Wadley
-
Weight (KG):
-
1700
-
Power (kW):
-
7.5
-
Product name:
-
Dk77
-
Type:
-
Fast Wire Cutting
-
Application:
-
Moulds Machining
-
Max. cutting thickness(mm):
-
450mm
-
Working weight:
-
450kg
-
Precision:
-
0.01mm
-
Function:
-
Mould Processing
-
Payment:
-
LC Paypal Etc
-
Surface Roughness:
-
Ra<2.5um
-
Color:
-
Customers Optional
High Quality DK7745 Desktop Cabinet DRO Edm Wire Cutting Machine For Mould Machining
Wire Cut Electrical Discharge Machining (WEDM), sometimes called wire cutting. The basic working principle is to use a continuous moving thin wire (called a wire) as an electrode, and perform pulse spark discharge on the workpiece to remove metal and cut.
WEDM is a kind of special processing. It is different from traditional processing technology. It needs mechanical and mechanical energy to cut off. It mainly uses electric energy to realize the processing of materials. Therefore, the WEDM technology is not limited by the material properties, and can process any hardness, strength and brittle material, which plays an important role in the current machining process.
|
Model |
Worktable size (mm) |
Worktable travel (mm) |
Max. cutting thickness (mm) |
Processing taper |
Max. load weight (kg) |
Main machine weight(kg) |
|
DK7720 |
270x420 |
200x250 |
200 |
6°/80mm |
100 |
800 |
|
DK7725 |
250x320 |
250x320 |
400 |
6°/80mm |
200 |
1200 |
|
DK7732 |
380x600 |
320x400 |
400 |
6°/80mm |
300 |
140 0 |
|
DK7740 |
410x710 |
400x500 |
400 |
6°/80mm |
450 |
1600 |
|
DK7745 |
500x750 |
450x550 |
400 |
6°/80mm |
450 |
1650 |
|
DK7755 |
596x880 |
550x650 |
500 |
6°/80mm |
800 |
2500 |
|
DK7763 |
790x1260 |
630x1000 |
600 |
6°/80mm |
1000 |
3500 |
|
DK7780 |
900x1500 |
800x1200 |
600 |
6°/80mm |
1500 |
5500 |
|
DK77100 |
1010x1500 |
1000x1200 |
600 |
6°/80mm |
1500 |
5600 |
|
DK77120 |
1300x1900 |
1200x1600 |
600 |
6°/80mm |
4000 |
10000 |
Product Feature:
X, Y, U, V axis are the stepping motor(servo motors are optional)
Electrical and control system integrated control cabinet of machine with the high-performance pulse power supply
Programming system: Autocut/ HL/ HF programming and control software
Only once cutting
Ordinary steel guideway/ linear guideway
Small water tank without paper core filtering
