Quick Details
-
Model Number:
-
Prefab House, ST258
-
Structure:
-
Steel frame/ Roof/ Wall/ Ceiling/ Floor
-
Steel frame:
-
Light steel structure
-
Ceiling:
-
PVC ceiling or customized
-
Wall:
-
EPS/PU/Rock wool sandwich panel
-
Uses:
-
Carport, House, Office, Warehouse, Workshop
-
Roof:
-
PU tile or EPS sandwich panel
-
Shape:
-
Sloped roof or flat roof prefabricated house
-
Window/ Doors:
-
Steel composite Door/ Plastic steel frame window
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Moneybox
-
Material:
-
Sandwich Panel
-
Model Number:
-
Prefab House, ST258
-
Structure:
-
Steel frame/ Roof/ Wall/ Ceiling/ Floor
-
Steel frame:
-
Light steel structure
-
Ceiling:
-
PVC ceiling or customized
-
Wall:
-
EPS/PU/Rock wool sandwich panel
-
Uses:
-
Carport, House, Office, Warehouse, Workshop
-
Roof:
-
PU tile or EPS sandwich panel
-
Shape:
-
Sloped roof or flat roof prefabricated house
-
Window/ Doors:
-
Steel composite Door/ Plastic steel frame window
-----------------------------------------------------------------------------------------------------------------------------
Our main products are as follows:
1. Light Steel Villa/ House/ Hotel
2. 20ft/ 40ft Container House/ Box
3. Light Steel Guard House/ Mobile Store / Toilet
4. Flat/ Slope/ Hipped Roof Prefab House
5. Light Steel Structure
6. Sandwich Panel
7. Decorative Materials
-----------------------------------------------------------------------------------------------------------------------------
Specification
| No. | Component | Description | Thickness |
| 1 | Main Steel Structure | 8#C Steel,Square Tube,Angle Iron,Flat Tube, Round Tube | 2.0mm |
| 2 | Roof Tile | PU or EPS Tile | 20-150mm |
| 3 | External Wall Panel | 50-250mm EPS,PU,Rockwool or EPS Cement with Two-sides Color Steel Sandwich Panel | 0.326mm for Color Steel Sheet |
| 4 | Door | Color Steel Sandwich Panel Door | 870mm(W) × 2100mm(H) |
| 5 | Window | PVC Sliding Window | 1200mm(W) x 1000mm(H) 1748mm(W) × 925mm(H) |
| 6 | Flooring | Plywood or PVC | 15/20mm |
| 7 | Celling | PVC or Gypsum Board | 8-12mm |
| Technical Paremeter | |||
| No. | Description | Specification | |
| 1 | Bearing Load | 150kg/square meters | |
| 2 | Wind Pressure | 0.45KN/square meters Equal 10 Grade | |
| 3 | Earthquake Resistance | 8 Grade | |
| 4 | Temperature Resistance | (-45°C) to 50 °C | |
| 5 | Life Span |
More Than 10 years
|
|
-----------------------------------------------------------------------------------------------------------------------------
Notice:
1 . Don't try to disassemble any bolt or part.
2 . Non-professional personnel shall not change the structure of houses.
3 . Please do not run or jump in the upstairs and use fire stoves indoors.
4 . Open or close the windows should be gently.
5 . The loading of the floor shall not exceed the bearing weight.
6. The easy corrosion steel parts are needed regular m ai ntenance,such as rust cleaning,painting, renovating,etc.
-----------------------------------------------------------------------------------------------------------------------------
