Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Top brand, Top brand
-
Model Number:
-
SEM816d, SEM816D
-
Dimension(Long * Breadth * High):
-
5447*3442*3160mm
-
Operating Weight:
-
16900kg
-
Max. Slope:
-
30°
Quick Details
-
Machine Weight:
-
16900 KG
-
Dozing Capacity:
-
4m³
-
Marketing Type:
-
New Product, New Product
-
Place of Origin:
-
China
-
Brand Name:
-
Top brand, Top brand
-
Model Number:
-
SEM816d, SEM816D
-
Dimension(Long * Breadth * High):
-
5447*3442*3160mm
-
Operating Weight:
-
16900kg
-
Max. Slope:
-
30°
Efficient:
The electronically controlled hydrostatic drive system and multi functional joystick provide high levels of performance and maneuverability
Comfortable Operation:
The cabin is ergonomically designed for increased operator comfort and visibility. The advanced monitoring system tracks machine operating conditions and keeps the operator informed of all vital machines functions
Reliable:
The proven hydrostat design along with world class pump and motors provide a highly reliable tractor. The undercarriage components are designed for longer life versus the leading competitor
Serviceability:
The SEM tractors are designed for easy access to reduce overall maintenance time. The machines electronic control module allows for quick troubleshooting
| Model | SEM816D | SEM816D LGP | SEM816D DS |
| Main Specifications | |||
| Operating Weight | 16,900kg | 19,490kg | 19,760kg |
| Ground Pressure | 66.8kPa | 31.1kPa | 34.8kPa |
| Ground Clearance | 410mm | 410mm | 410mm |
| Engine | |||
| Engine Model | WD10G178E25 | WD10G178E25 | WD10G178E25 |
| Rated Power | 131kW | 131kW | 131kW |
| Working Tool | |||
| Blade Type | SU / S | LGP | LGP |
| Blade Width | 3,180mm / 3,590mm | 4,410mm | 4,410mm |
| Blade Height | 1,240mm / 1,165mm | 1,000mm | 1,000mm |
| Max. Blade Digging Depth | 430mm / 430mm | 470mm | 470mm |
| Max.Blade Lift Ground Clearance | 1,041mm / 1,041mm | 1,055mm | 1,055mm |
| Max.Output Rimpull | 280kN | 280kN | 280kN |
| Max. Digging Depth of Ripper | 584mm | / | / |
| Max. Clearance Under Tip | 615mm | / | / |
| Powertrain | |||
| Type | dual-path, closed loop electronically controlled hydrostatic drive system | ||
| Travel Speed-F/R | infinitely variable speeds 0-10 km/h | ||
| Steering & Brake | hydrostatic steering; wet,multi-disc brake | ||
| Minimum Streeing Radius | 3610mm | 3740mm | 3740mm |
| Undercarriage | |||
| Track Shoe Width-Single | 510mm | / | 950mm |
| Track Shoe Width-APEX | / | 1050mm | 950mm |
| Track Shoe Quantity | 37 | 42 | 42 |
| Length Of Track On Ground | 2430mm | 2925mm | 2925mm |
| Track Gauge | 1880mm | 2300mm | 2300mm |
| Track Roller Quantity | 6 | 7 | 7 |
| Carrier Roller Quantity | 2 | 2 | 2 |
| Hydraulic System | |||
| Type | center close, pilot control | ||
| Implement Hydraulic System Pressure | 19 MPa | ||
| Service Refill Capacities | |||
| Fuel Tank | 320L | 320L | 320L |
| Cooling System | 45L | 45L | 45L |
| Engine Crankcase | 24L | 24L | 24L |
| Final Drive (each side) | 30L | 30L | 30L |
| Hydraulic Tank | 140L | 140L | 140L |
| Pivot Shaft Case (each side) | 1.2L | 1.2L | 1.2L |
