Quick Details
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
370*185MM
-
Panel Efficiency:
-
max 20%
-
Type:
-
ETFE Semi Flexible solar panel
-
Grade:
-
A grade
-
Solar Cell:
-
Back contact Sunpower cells
-
Junction box:
-
IP65 Rated Standard Waterproof with bypass diode
-
Weight:
-
2.5kg
-
Application:
-
Marine,Boat, Yachts,camping solar system, Golf car
-
Material:
-
Mono-crystalline Silicon
-
Customized:
-
Available
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
-
Warranty:
-
5 years Full warranty on the Material and workmanship
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Brand Name:
-
HETECH
-
Model Number:
-
HT-10FM
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
370*185MM
-
Panel Efficiency:
-
max 20%
-
Type:
-
ETFE Semi Flexible solar panel
-
Grade:
-
A grade
-
Solar Cell:
-
Back contact Sunpower cells
-
Junction box:
-
IP65 Rated Standard Waterproof with bypass diode
-
Weight:
-
2.5kg
-
Application:
-
Marine,Boat, Yachts,camping solar system, Golf car
-
Material:
-
Mono-crystalline Silicon
-
Customized:
-
Available
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
-
Warranty:
-
5 years Full warranty on the Material and workmanship
Please send inquiry to us!
|
ELECTRICAL CHARACTERISTICS
|
|
|
|
Max Power - Pm
|
10W
|
|
|
Open Circuit Voltage - Voc
|
6.12V
|
|
|
Short Circuit Current - Isc
|
2.01A
|
|
|
Max Power Voltage - Vmp
|
5.2V
|
|
|
Max Power Current - Imp
|
1.93A
|
|
|
Module Dimension
|
370*185*2.5mm
|
|
|
Module Weight
|
0.25Kg
|
|
|
Max system voltage
|
500VDC
|
|
|
Series fuse rating
|
15A
|
|
|
Standard Test Conditons[STC]:irradiance 1000W/M2 ; >AM1.5;ambient temperature 25°C according to EN 60904-3;
|
|
|
