Quick Details
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
1600x1200x1600
-
Weight (KG):
-
1100
-
Power (kW):
-
2
-
Workbench size:
-
470*760mm
-
Work Table Size:
-
350x450mm
-
Max. cutting thickness(mm):
-
450mm
-
Machined taper:
-
6 Degrees/80mm
-
Max.load:
-
500kg
-
Machining accuracy:
-
0.01-0.015
-
Wire Diameter (mm):
-
0.10-0.20mm
-
Max Productivity Speed (mm2/min):
-
180mm /min
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Year:
-
2024
-
Brand Name:
-
spaite
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
1600x1200x1600
-
Weight (KG):
-
1100
-
Power (kW):
-
2
-
Workbench size:
-
470*760mm
-
Work Table Size:
-
350x450mm
-
Max. cutting thickness(mm):
-
450mm
-
Machined taper:
-
6 Degrees/80mm
-
Max.load:
-
500kg
-
Machining accuracy:
-
0.01-0.015
-
Wire Diameter (mm):
-
0.10-0.20mm
-
Max Productivity Speed (mm2/min):
-
180mm /min
|
Model
|
Worktable size(mm)
|
Worktable travel(mm)
|
Max. cutting thickness(mm)
|
Machined taper
|
Machine
weight |
Max workinpece
weight |
Machine dimensio
|
|
DK7720
|
250×300mm
|
200×250mm
|
150mm
|
/
|
600kg
|
200kg
|
1400×1200mm
|
|
DK7735
|
470×760mm
|
350×450mm
|
600mm
|
6°/B0mm
|
1200kg
|
500kg
|
1600×1200mm
|
|
DK7745
|
670×850mm
|
450×550mm
|
500mm
|
6°/80mm
|
1600kg
|
800kg
|
1800×1400mm
|
|
DK7745J
|
570×960mm
|
450×650mm
|
500mm
|
6°/80mm
|
1800kg
|
800kg
|
1800×1600mm
|
|
DK7755
|
680×980mm
|
550×650mm
|
800mm
|
6°/80mm
|
2400kg
|
1200kg
|
2150×1700mm
|
|
DK7755J
|
680×1160mm
|
550×800mm
|
800mm
|
6°/80mm
|
2600kg
|
1200kg
|
2150×1900mm
|
|
DK7763
|
750×1160mm
|
630×800mm
|
800mm
|
6°/80mm
|
3200kg
|
1500kg
|
2300×2200mm
|
|
DK7763J
|
750×1360mm
|
630×1000mm
|
800mm
|
6°/80mm
|
3500kg
|
1500kg
|
2300×2200mm
|
|
DK7780
|
980×1350mm
|
800×1000mm
|
800mm
|
6°/80mm
|
4500kg
|
1800kg
|
2600×2400mm
|
|
DK7780J
|
980×1580mm
|
800×1200mm
|
800mm
|
6°/80mm
|
5000kg
|
1800kg
|
2800×2400mm
|
|
DK77100
|
1160×1600mm
|
1000×1200mm
|
800mm
|
6°/80mm
|
6000kg
|
1800kg
|
3000×2800mm
|
|
DK77120
|
1500×2100mm
|
1200×1600mm
|
800mm
|
6°/80mm
|
11000kg
|
1800kg
|
3800×3800mm
|
|
|
DK7732C
|
DK7740C
|
|
|
Worktable size(mm)
|
490X740
|
590X850
|
|
|
X-axis stroke(mm)
|
320
|
400
|
|
|
Y-axis stroke(mm)
|
400
|
500
|
|
|
Max. cutting thickness(mm)
|
200
|
|
|
|
Max workinpece weight
|
250KG
|
|
|
|
Auxiliary axis movement distance
(U * V axis)(mm) |
30×30mm
|
|
|
|
Standard cutting inclination(degree/mm)
|
+3/80mm
|
|
|
|
Cutting molybdenum wire diameter(mm)
|
0.10~0.18
|
|
|
|
Multiple cutting accuracy(mm)
|
S+0.005(15×15Octagonal shape，Gr12,s=40)
|
|
|
|
positioning accuracy(mm)
|
S+0.01
|
|
|
|
Repeat positioning accuracy(mm)
|
S+0.003
|
|
|
|
Optimal surface roughness(um)
|
Ra≤1.5
|
|
|
|
Maximum cutting efficiency(mm²/min)
|
150~180
|
|
|
|
Machine dimensio
(Width * length * height)(mm) |
1200×1800×2000
|
1400×2000×2000
|
|
|
Machine weight(kg)
|
m1600
|
≈1800
|
|
|
Control cabinet size
(width * length * height)(mm) |
600×600×1000
|
600×600×1000
|
|
|
Machine tool power consumption(kva)
|
≤3
|
≤3
|
|
Q1:What information do you need before making quotation?
A1:Worktable size or table travel you need.
Q2:How can I get technical support if I buy your machine?
A2:We have detailed instructional videos even if novices can operate by watching the videos. We also provide online operation training.
Q3:I'm worried about after-sale service!
A3:Warranty is one year. Any parts damaged during warranty will be replaced for free! We provide spare parts for life time at cost price.
Q4:Can you provide customzied machines?
A4:Yes, we have professional engineers and designers. We can design and manufacture according to your specific requirements. We can provide OEM services.
A4:Yes, we have professional engineers and designers. We can design and manufacture according to your specific requirements. We can provide OEM services.
Q5.When is the delivery time?
A5: If you order the standard machine, we can prepare within 10 days. If the equipment is customized, the time will be longer. You can place order according to delivery time and ship time.we will give you the answer accordingly.
Q6:Are you manufacturer?
A6:Yes,we are manufacturer. Welcome to visit us!
