Quick Details
-
Working Stroke:
-
45mm
-
Extrusion Rebar Diameter:
-
16-32mm (Customizeable)
-
Pressure:
-
63mpa
-
Motor Power:
-
4kw
-
Voltage:
-
380v or other customized voltage
-
Weight:
-
120kg
-
Oil Pump Dimension:
-
800*600*800mm
-
Extrusion Head Dimension:
-
500*170*200mm
-
Type:
-
Hydraulic Aluminum Extrusion Press Machine Press Machine For Aluminium
-
After-sales Service Provided:
-
Online support, Video technical support
-
After Warranty Service:
-
Video technical support, Online support
-
Local Service Location:
-
None
Quick Details
-
Place of Origin:
-
China
-
Marketing Type:
-
New Product 2021
-
Product name:
-
Hydraulic Aluminum Extrusion Press Machine Press Machine For Aluminium
-
Working Stroke:
-
45mm
-
Extrusion Rebar Diameter:
-
16-32mm (Customizeable)
-
Pressure:
-
63mpa
-
Motor Power:
-
4kw
-
Voltage:
-
380v or other customized voltage
-
Weight:
-
120kg
-
Oil Pump Dimension:
-
800*600*800mm
-
Extrusion Head Dimension:
-
500*170*200mm
-
Type:
-
Hydraulic Aluminum Extrusion Press Machine Press Machine For Aluminium
-
After-sales Service Provided:
-
Online support, Video technical support
-
After Warranty Service:
-
Video technical support, Online support
-
Local Service Location:
-
None
Hydraulic Aluminum Extrusion Press Machine Press Machine For Aluminium
Steel bar cold extrusion press machine is a kind of steel bar processed equipment , which is mainly used for the connection of various steel bars in some engineering constructions, such as, reinforced concrete structure construction, high-rise frame construction, ordinary ways, high ways, ordinary railways, high-speed railways, tunnels, bridges, airport construction, flood control dams, earthquake-resistant buildings, marine breakwater dams, etc. The rebar cold extrusion press machine manufactured by Deleixi Machinery is suitable for machining steel bars with the diameters of 16 to 32mm or we can customize for you according to your needs.
| Model | JYJ-32 |
| Extrusion Rebar Diameter | 16-32mm (Customizeable) |
| Working Stroke | 45mm |
| Pressure | 63mpa |
| Motor Power | 4kw |
| Voltage | 380v or other customized voltage |
| Weight | 120kg |
| Oil Pump Dimension | 800*600*800mm |
| Extrusion Head Dimension | 500*170*200mm |
Technical Parameter of the Cold Extrusion Press Rebar Couplers:
|
Rebar Diameter |
OD*Length |
Weight |
|
16mm |
0.28kg/pc |
|
|
18mm |
Φ34*118mm |
0.38kg/pc |
|
20mm |
Φ35*120mm |
0.48kg/pc |
|
22mm |
Φ40*132mm |
0.68kg/pc |
|
25mm |
Φ45*150mm |
1kg/pc |
|
28mm |
Φ50*168mm |
1.47kg/pc |
|
32mm |
Φ55.5*192mm |
2.03kg/pc |
What You Should Be Careful When Using The Machine:
- The rust, sand, oil and other debris of the steel bar must be cleaned up.
- Mark the ends of the steel bars to be connected with paint.
- For a few steel bars that can’t be inserted into the couplers after exceeding tolerance, please grind the longitudinal at the end by grinding wheels in advance.
- Cold extrusion rebar couplers should be stored according to different specifications to prevent the interaction between different diameters of steel.
Packing a nd Shipping
1. Packaging: 1)Wrapped by proctective film;
2)Packed by standard import & export wooden cases or carton boxes.
2. Shipping: By logistics; by automobile; by train; by shipping; by air etc.
