> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 years
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM350P-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40/mm
-
Frame:
-
Anodized aluminium alloy
-
Solar cell:
-
Solar Panel Poly 156*156 cell
-
Front cover:
-
3.2mm High Transmissivity, Low Iron tempered glass
-
Frame Color:
-
Color Silvery, Black
-
OEM:
-
Acceptable
-
Product name:
-
Polycrystalline Solar Panles
-
Backing Color:
-
White, Black
-
Weight:
-
21kg
-
Certificate:
-
CE/TUV/ETL
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
PERC, hbc
-
Panel Efficiency:
-
18%
-
Warranty:
-
25 years
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM350P-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40/mm
-
Frame:
-
Anodized aluminium alloy
-
Solar cell:
-
Solar Panel Poly 156*156 cell
-
Front cover:
-
3.2mm High Transmissivity, Low Iron tempered glass
-
Frame Color:
-
Color Silvery, Black
-
OEM:
-
Acceptable
-
Product name:
-
Polycrystalline Solar Panles
-
Backing Color:
-
White, Black
-
Weight:
-
21kg
-
Certificate:
-
CE/TUV/ETL
Product Description
|
Moduel
|
BSM335P-72
|
BSM340P-72
|
BSM345P-72
|
BSM350P-72
|
BSM355P-72
|
||||
|
Rated Maximum Power at STC
|
335
|
340
|
345
|
350
|
355
|
||||
|
Open Circuit Voltage(Voc/V)
|
46.3
|
46.5
|
46.7
|
46.9
|
47.0
|
||||
|
Maximum PowerVoltage(Vmp/V)
|
37.9
|
38.2
|
38.4
|
38.5
|
38.7
|
||||
|
Short Circuit Current(Isc/A)
|
8.84
|
8.90
|
9.00
|
9.09
|
9.17
|
||||
|
Maximum Power Current(Imp/A)
|
9.36
|
9.45
|
9.50
|
9.60
|
9.69
|
||||
|
Module Efficiency(%)
|
17.3
|
17.5
|
17.8
|
18.0
|
18.3
|
||||
|
Power Tolerance
|
-0~+5%
|
|
|
|
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m
2
,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|
||||
Detailed &Production
Glass
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
Project
250KW on grid solar project in Malta, EU
60KW on grid solar project in Guatemala, South America
1.2MW solar power plant in Ecuador, South America
147KW on grid solar project in California, USA
150KW on grid solar project in Japan
Payment
|
Payment Term
|
T/T
|
EXW
|
|
||
|
|
|
FOB
|
|
||
|
|
|
CFR(C&F)
|
|
||
|
|
|
CIF
|
|
||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
||
|
|
Paypal
|
Amount lower than 5000usd
|
|
||
|
|
West Union
|
|
|
||
|
Delivery Time
|
10 working days after receiving payment for one container
|
|
|
||
We welcome use Trade Assurance, you'll enjoy:
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
