Quick Details
-
Weight (KG):
-
180
-
Type:
-
Horizontal Brake Disc Turning Tool
-
Product name:
-
FC9335
-
Processing diameter Brake Drum:
-
180-350mm
-
Processing diameter Brake Disc:
-
180-430mm
-
Max. travel of tool:
-
140mm
-
Overall dimensions:
-
800*550*700mm
-
N.W/G.W:
-
160/180kg
-
Motor power:
-
0.75kw
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MILLART
-
Marketing Type:
-
Hot Product 2023
-
Weight (KG):
-
180
-
Type:
-
Horizontal Brake Disc Turning Tool
-
Product name:
-
FC9335
-
Processing diameter Brake Drum:
-
180-350mm
-
Processing diameter Brake Disc:
-
180-430mm
-
Max. travel of tool:
-
140mm
-
Overall dimensions:
-
800*550*700mm
-
N.W/G.W:
-
160/180kg
-
Motor power:
-
0.75kw
Product Description
Feature
1. Quickly, accurately and efficiently to cutting rotor.
2. Fast and slow setting allow cutting rotor.
3. Quickly, accurately and efficiently to cutting drum.
4. Finitely adjustable setting allow cutting drum.
5. Different speed to choose for spindle speed.
6. A convenient design allows to quickly change from rotor to drum, with cross feed extension plate will be increase the maximum rotor diameter to 22'/588mm.
7. Position of stop make the lathe stop automatically after cutting.
8. Fully equipped with adapter package.
Product Details
|
Main specifications
|
|
FC9335
|
|
|
Processing diameter mm
|
Brake Drum
|
180-350
|
|
|
|
Brake Disc
|
180-430
|
|
|
Rotating speed of work-piece r/min
|
|
0-140
|
|
|
Max. travel of tool mm
|
|
140
|
|
|
Overall dimensions (L x W x H) mm
|
|
800 x 550 x 700
|
|
|
N.W/G.W kgs
|
|
160/180
|
|
|
Motor power kw
|
|
0.75
|
|
