Quick Details
-
Model Number:
-
TS2520-0AM10-R10
-
Max. Current:
-
6A
-
Protect Level:
-
IP65, IP67
-
Electrical Endurance:
-
600,000 Cycles
-
Rated current:
-
6A/230V; 4A/380V
-
Certificate:
-
CCC CE
-
Insulation Resistance:
-
>=100MΩ
-
Insulation Voltage:
-
600V
-
Conventional Thermal Current:
-
10A
-
Mechnical Endurance:
-
Momentary 5,000,000; Latch:500,000
-
Mounting Type:
-
Screw Mounting
-
Color Option:
-
Red Green Yellow Blue White Black
-
Certification:
-
CCC CE
Quick Details
-
Max. Voltage:
-
600V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SUPU
-
Model Number:
-
TS2520-0AM10-R10
-
Max. Current:
-
6A
-
Protect Level:
-
IP65, IP67
-
Electrical Endurance:
-
600,000 Cycles
-
Rated current:
-
6A/230V; 4A/380V
-
Certificate:
-
CCC CE
-
Insulation Resistance:
-
>=100MΩ
-
Insulation Voltage:
-
600V
-
Conventional Thermal Current:
-
10A
-
Mechnical Endurance:
-
Momentary 5,000,000; Latch:500,000
-
Mounting Type:
-
Screw Mounting
-
Color Option:
-
Red Green Yellow Blue White Black
-
Certification:
-
CCC CE
Products Description
|
Standard |
GB/T14048.5 IEC60947-5-1
|
|
Storage Ambient Temperature |
-45℃~80℃
|
|
Usage Ambient Temperature |
-25℃~55℃
|
|
Protection Level |
IP65 IP67
|
|
Insulation Resistance |
≥100MΩ
|
|
Contact Resistance |
≤50mΩ
|
|
Power frequency withstand voltage |
2500V·1min
|
|
Vibration resistance |
10…500Hz 5g
|
|
Insulation Volgate |
600V
|
|
Conventional thermal current |
10A(AC)
|
|
Mechnical Endurance(Cycles) |
-
|
|
Electrical Endurance |
AC15:100000
|
|
|
DC13:50000
|
|
Contact Rated Capacity |
-
|
|
Specifications of
special contact blocks |
-
|
|
Contact material
|
Silver alloy(AgNi)
|
|
|
-
|
|
Impact resistance
|
11ms,50g,Half wave sine
|
|
Mounting Type |
Screw connection
|
|
Installation twisting
|
Max 0.8N.M
|
|
ROHS Material |
Yes
|
|
Light Modules |
-
|
|
MTBF |
More than 600000 times
|
