- Product Details
- {{item.text}}
Quick Details
-
Running Noise:
-
<50dB
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Opening/Closing Time:
-
0.9 Sec
-
Max Power Consumption(Operating):
-
150
-
Running Noise:
-
<50dB
1, High efficient servo motor, low power high output, energy saving and environmental friendly.
2, Efficient and precise planetary reducer drive, 5-10 million service times, completely maintenance-free during its service.
3, Advanced servo controlling system, fast speed, high accuracy and intelligent self-inspection.
4, High security. Automatic lift when power off, anti-collision and Auto-reverse, auto-stop when hitting obstacle.
5, All-weather adaptability. Excellent water proof and dust proof function, compatible with solar system.
6, Creative Five “Without” Design:
Without position sensor, precise stop position, perfectly synchronized for two opposite barrier gate.
Without shock absorption rubber brick, no impact, no bounce, adjustment free.
Without clutch device, automatically lifting when power off, or can be set as unlocking when power off(under this setting, barrier arm can be lifted manually)
Without keyway design, no more worries about hidden danger by the gap between key and keyway and the lever jitter problem.
Without brake design, no more worries about problem cuased by break wear and the resulting reliability problem.
|
Model No. |
BG3009 |
|
Boom Length/Sectional Size |
≤3m/ Φ 75mm Octagonal bar 80*46mm |
|
Open/Close Time |
0.9 sec |
|
Motor Power |
DC24V, 150W |
|
Max Power Consumption(Operating) |
max.150W |
|
Max Power Consumption(Standby) |
8 W |
|
Power Supply |
24/100/240VAC,50/60Hz |
|
Control Voltage |
24V DC/max.3000mA |
|
Service Life |
5-10 million times |
|
Motor No-load Speed |
3000r/min |
|
Machine Case Thickness/Surface Treatment |
2.0mm steel plate/outdoor electrostatic powder spray |
|
Driving Method |
Servo motor+Planetary reducer |
|
Protection Level |
IP54 |
|
Operating Temperature / Relative Humidity |
-45℃~+85℃ / ≤90% |
|
Running Noise |
<50 dB |
|
Machine Case Size(W*D*H) |
332*323*960mm |
|
Package Size |
383*499*1033mm |
|
Weight |
51KG |
