Quick Details
-
Ice storage capacity:
-
1000kg
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZXSHARE
-
Weight:
-
5000 KG
-
Certification:
-
ce
-
After-sales Service Provided:
-
Free spare parts
-
Refrigeration type:
-
Direct cooling
-
Compressor:
-
Bitzer
-
Material:
-
aluminium
-
Refrigerant:
-
R404A/R22
-
Cooling way:
-
Air/water cooling
-
Expansion Valve:
-
Denmark Brand Danfoss
-
Electrical components:
-
France brand Schneider
-
Control system:
-
PLC &Touch screen
Quick Details
-
Ice Shape:
-
ICE BLOCK
-
Voltage:
-
380v/50hz/3p
-
Power:
-
50KW
-
Ice storage capacity:
-
1000kg
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZXSHARE
-
Weight:
-
5000 KG
-
Certification:
-
ce
-
After-sales Service Provided:
-
Free spare parts
-
Refrigeration type:
-
Direct cooling
-
Compressor:
-
Bitzer
-
Material:
-
aluminium
-
Refrigerant:
-
R404A/R22
-
Cooling way:
-
Air/water cooling
-
Expansion Valve:
-
Denmark Brand Danfoss
-
Electrical components:
-
France brand Schneider
-
Control system:
-
PLC &Touch screen
1. Add water into the ice moulds.
2. Turn on the ice block machine
3. Turn off the ice block machine, ice making time different from ice weight and thickness.
4. Wait minutes, ice blocks will be fully frozen with the remained coldness
5. Press the ice harvest button, hot gas will into the aluminum ice moulds, ice block will be separated from the ice moulds, then release the ice platform, all ice blocks dropping down on the platform;
Faster ice Making /Lower power consumption Clean ice Block Making
Model list:
|
Block Ice Machine |
|||||||
|
Model |
Daily Output |
Ice Weight |
Total Power |
Compressor |
Cooling Type |
Dimension |
Weight |
|
ZB1.0T-R4A |
1.0T/24h |
10/15/20/25Kg |
6.4kW |
Copeland |
Air cooling |
2050*1000*800mm |
800Kg |
|
ZB3.0T-R4A |
3.0T/24h |
10/15/20/25Kg |
14.3kW |
Bitzer |
Water cooled |
2473*1557*720mm |
1400Kg |
|
ZB5.0T-R2W |
5.0T/24h |
10/15/20/25Kg |
25.9kW |
Bitzer |
Water cooled |
4735*1580*1130mm |
2650Kg |
|
ZB8.0T-R2W |
8.0T/24h |
10/15/20/25Kg |
41.5kW |
Bitzer |
Water cooled |
5160*1820*1400mm |
4000kg |
|
ZB10.0T-R2W |
10.0T/24h |
20/25/50/100Kg |
48.2kW |
Hanbell |
Water cooled |
6280*2000*1600mm |
4650Kg |
|
ZB15.0T-R2W |
15.0T/24h |
20/25/50/100Kg |
53.3kW |
Hanbell |
Water cooled |
9800*2000*1500mm |
5000Kg |
|
ZB20.0T-R2W |
20.0T/24h |
20/25/50/100Kg |
69kW |
Hanbell |
Water cooled |
12600*1940*1500mm |
5500Kg |
|
ZB25.0T-R2W |
25.0T/24h |
20/25/50/100Kg |
97.8kW |
Hanbell |
Water cooled |
13500*2800*1600mm |
6000Kg |
|
ZB30.0T-R2W |
30.0T/24h |
20/25/50/100Kg |
123kW |
Hanbell |
Water cooled |
14600*3000*1600mm |
6500Kg |
|
ZB40.0T-R2W |
40.0T/24h |
20/25/50/100Kg |
166kW |
Hanbell |
Water cooled |
19500*3800*1600mm |
7500Kg |
|
ZB50.0T-R2W |
50.0T/24h |
20/25/50/100Kg |
182kW |
Hanbell |
Water cooled |
13300*6200*1560mm |
8000Kg |
