Quick Details
-
Model Number:
-
EP250
-
Material:
-
Rubber,Polyester,Nylon
-
Width:
-
500-2400mm
-
Length:
-
Customized Length
-
Operating Temperature:
-
-45℃ to 180℃
-
Tensile Strength:
-
300-2000N/mm
-
Abrasion Resistant:
-
Excellent
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XTO
-
Model Number:
-
EP250
-
Material:
-
Rubber,Polyester,Nylon
-
Width:
-
500-2400mm
-
Length:
-
Customized Length
-
Operating Temperature:
-
-45℃ to 180℃
-
Tensile Strength:
-
300-2000N/mm
-
Abrasion Resistant:
-
Excellent
We produces high-quality stable conveyor belts, and the product performance meets the requirements of DIN, RMA, AS,JIS,BS and so on.Can be developed and produced according to customer requirements.
It is suitable for conveying high temperature solid materials like sintering ore, coke, cement clinker, etc. which is used in metallurgical, cement, chemical industry and so on.
Characteristics
1.Developed new structure carcass materials will reduce the strength loss of heat aging during running, and thus will extend the working life.
2.The cover uses superior ethylene-propylene rubber or halogenate rubber which will enhance the high temperature resistant property of the rubber and reduce the loss of heat aging.
Standard Specifications
|
Strength（KN/m）
|
No. Of Piles
|
Carcass Type
|
Belt Width
|
|
300
|
2-4
|
NN/EP
|
500-2400mm |
|
400
|
2-4
|
NN/EP
|
|
|
500
|
2-5
|
NN/EP
|
|
|
630
|
3-6
|
NN/EP
|
|
|
800
|
3-6
|
NN/EP
|
|
|
1000
|
3-6
|
NN/EP
|
|
|
1250
|
3-6
|
NN/EP
|
|
|
1400
|
3-6
|
NN/EP
|
|
|
1600
|
4-6
|
NN/EP
|
|
|
2000
|
4-6
|
NN/EP
|
|
Note: It can be customized according to customers’ requirements.
Covers grades
|
Item
|
|
GB20021Standard
|
|
|
|
||||
|
|
|
T1
|
T2
|
T3
|
T4
|
||||
|
|
|
Test Temperature
|
|
|
|
||||
|
|
|
≤100℃
|
≤125℃
|
≤150℃
|
≤175℃
|
||||
|
|
|
Permitted change range
|
|
|
|
||||
|
Hardness
|
Difference
Before and after aging |
+20
|
+20
|
±20
|
±20
|
||||
|
|
Maximum after aging
|
85
|
85
|
85
|
85
|
||||
|
Tensile strength
|
Change rate of property %
|
-25
|
-30
|
-40
|
-40
|
||||
|
|
Minimum value after aging
|
12
|
10
|
5
|
5
|
||||
|
Elongation at break
|
Change rate after aging %
|
-50
|
-50
|
-55
|
-55
|
||||
|
|
Minimun value after aging
|
200
|
200
|
180
|
180
|
||||
The values will help to determine the appropriate cover compound for the application or for the
materials carries. Reliable assessment of the behavior of the covers in service for wear and cut
resistance cannot be determined from tensile strength, and abrasion values alone.
PS:The above standards are in accordance with Chinese standards, and can be customized according to the standards provided by customers.Such as DIN-X,Y,W,RMA-1,RMA-2.
Perfect Testing Equipment
We have a strong ability to develop new products. The company has an area of 3800 square meters of scientific research building.Four rubber material laboratories have been established, including material testing, formula testing, rubber mixing test and finished product testing, truly realize the strict control testing from raw materials to finished products, to ensure that the quality of products to meet the needs of us.
We are proud to have established long-term partnerships with many outstanding companies. These partners come from different industries, such as mining, manufacturing, logistics and transportation. For example, Ordered by BHP, RIO-TINTO, VALE repeatedly.We are committed to providing customers with efficient and reliable material handling solutions, and through close cooperation, we realize the sharing of resources and complementary advantages, and create greater value for customers.
