Quick Details
-
Voltage:
-
customized
-
Place of Origin:
-
Liaoning, China
-
Year:
-
2021
-
Brand Name:
-
fuyi
-
Dimension(L*W*H):
-
1000*640*1300mm
-
Weight (KG):
-
130
Quick Details
-
Production Capacity:
-
6-8 pcs/min
-
Automatic Grade:
-
semi-auto
-
Driven Type:
-
pneumatic
-
Voltage:
-
customized
-
Place of Origin:
-
Liaoning, China
-
Year:
-
2021
-
Brand Name:
-
fuyi
-
Dimension(L*W*H):
-
1000*640*1300mm
-
Weight (KG):
-
130
Product Description
5-30L Semi auto adhesive grease sealant cartridge filling machine
Product introduction:
It is an explosion-proof filling machine, more suitable for petrochemical, food, military and other enterprises working environment. It adopts liquid level filling method and is suitable for a variety of liquid materials. The unique spray gun device is easy to operate, fast and accurate pouring, and ensures the leakage of residual liquid at the end of filling.
Feature:
Filling range is adjustable.
Anti-explosion and anti-corrosive.
Can equip lifting gun as per you request to avoid splashing liquid or foam.
Automatic weighing, easy to operate.
Can equip capping machine and production line.
The
Diaphragm pump can help you suck the material you will fill, the bag filter can help you to remove the purifies in the liquid. so that you can get a better filling effect.
Technical Parameter:
■Model: FY-30LW
■ maximum weighing capacity: 50kg
■
Minimum sensitivity: 0.005kg
■
Filling error: ± 0.1% F.S
■ filling speed: About 120-150 B / h (depending on feed flow rate)
■ power supply: AC220 / 50 Hz
■ air source: 0.6MPa
■ air source: 0.6MPa
■ service temperature: - 10 ℃ - 50 ℃
■ relative humidity: < 95% (non condensing)
■ control mode: 2-gear control (with reflux control)
■ filling method: plug-in, under the liquid level
■ platform size: 400 × 400mm Gun head pipeline: stainless steel and tetrafluoroethylene
■
Pipeline pressure: (0.2-0.6) MPa (related to material properties).
■ material interface: Dn40 threaded joint Gas source interface: the user provides G1 / 2 internal thread for quick
coupling connection
coupling connection
■ foundation conditions: for horizontal and solid concrete ground, the concrete thickness should be greater
than 10cm.
than 10cm.
Machine details:
