Quick Details
-
Warranty(Year):
-
5-Year
-
Input Voltage(V):
-
AC100-277V or AC100-240V
-
Model Number:
-
GM10, GM15, GM20,GM30,GM40, GM50
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SMART
-
UGR:
-
10-19
-
Beam angle:
-
60°90°
-
Input:
-
100-240V, 50-60Hz
-
CRI:
-
Ra80, Ra90, Ra97 (R9>95)
-
Dimmable:
-
Triac/0-10V/Dali ordered
-
Power Efficiency:
-
>0.95
-
Series Power:
-
10-50w
-
Installation Way:
-
Recessed
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
120
-
Lamp Body Material:
-
Aluminum
-
Install Style:
-
Downlights
-
Warranty(Year):
-
5-Year
-
Input Voltage(V):
-
AC100-277V or AC100-240V
-
Model Number:
-
GM10, GM15, GM20,GM30,GM40, GM50
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SMART
-
UGR:
-
10-19
-
Beam angle:
-
60°90°
-
Input:
-
100-240V, 50-60Hz
-
CRI:
-
Ra80, Ra90, Ra97 (R9>95)
-
Dimmable:
-
Triac/0-10V/Dali ordered
-
Power Efficiency:
-
>0.95
-
Series Power:
-
10-50w
-
Installation Way:
-
Recessed
MATERIAL: Dia-casting intergrated material
CCT: 2700K, 3000K, 4000K, 5000K, 6000K White
CRI: Ra80, Ra90, Ra97
UGR: 10-19
Output Efficiency: 110~130lm/W
INPUT: Ac100-240V, 50-60Hz, No-Flickering
DIMMABLE: Triac Dim, 0-10V Dim, Dali Dim, CCT-Dim (Ordered)
Warranty: 5 years
Application:Products are widely used as indoor main illumination lighting in theoffice,commercial center,shopping mall,supermarket,factory,etc.
PRODUCTS PARAMETERS PRODUCTS IMAGE:
| Item no. | Power | CRI | Color Kelvin (optional) | Lamp Illumination | Voltage | Beam angle (optional) | Reflector Cup | Color of housing | Dimension (mm) |
| SM-GM10 | 10W | 80 | 2700K-6500K | 600-950lm | AC220-240V | 15°24°38° | LGP+reflector Cup | white | ￠ 90 *H60 ￠ 75-80 (hole) |
| SM-GM15 | 15W | 80 | 2700K-6500K | 1100-1400lm | AC220-240V | 15°24°38° | LGP+reflector Cup | white | ￠ 102 *H80 ￠ 92-95 (hole) |
| SM-GM20 | 20W | 80 | 2700K-6500K | 1600-2500lm | AC220-2 40V | 15°24°38° | LGP+reflector Cup | white | ￠ 125xH108 ￠ 110-115(hole) |
| SM-GM30 | 30W | 80 | 2700K-6500K | 2900-3600lm | AC220-240V | 15°24°38° | LGP+reflector Cup | white | ￠ 140xH115 ￠ 125-130(hole) |
| SM-GM40 | 40W | 80 | 2700K-6500K | 3800-4500lm | AC220-240V | 15°24°38° | LGP+reflector Cup | white | ￠ 160xH135 ￠ 145-150(hole) |
| SM-GM50 | 50W | 80 | 2700K-6500K | 4800-5500lm | AC220-240V | 15°24°38° | LGP+reflector Cup | white | ￠ 190xH170 ￠ 175-180(hole) |
INSTALLATION:
>>>Click here to get catalogues now
SMART is also quite experienced on ODM&OEM cooperation with customers for personalized products, all new ideas are welcome here.
Q1. Do you have certificate for your products ?
A: Yes, for all of our products have CE (EMC+LVD), Rohs, C-tick, FCC, PSE, REACH, ERP etc. Certification
Q2. What's the warranty?
A: Our Commercial Light are 5 years warranty.
Q3. Can I have the sample light and What's the MOQ?
A: We very welcome you to set sample order to feel our quality, so MOQ=1, and mixed sample will acceptable.
Q4. How long is the delivery time?
A: Sample order is 3-5 days, massive order is 7-20 days depends on the quantity.
Q5. What's your payment terms please?
A: T/T in advance, L/C, Paypal, West Union.
Q6. How to move the order
A: Usually by Express DHL, FEDEX, TNT or UPS, and it will cost 3-5 days on the way, when the order is big, or By Air or By sea cost 10-25days on the way.
Q7. Is it okay to Print your company name or Logo on lamps
A: Yes, pls inform us before ordering
Q8. How to process one orde
A: 1> pls let me know your needed and requirement
2>according as your needed, we quote you all the cost
3> pls confirm all the details on the PI, and arrange the deposit
4> we arrange the production, and ship to you by express and tell you the tracking number to follow
