Quick Details
-
Voltage:
-
380v/3phase/50hz
-
Disc Dia.:
-
non
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Qiangxin
-
Model Number:
-
QX2000
-
Warranty:
-
1 year, one year guarantee
-
Lighting System:
-
32 Pcs 18w LED energy saving lamps
-
Heating System:
-
RIELLO G20 diesel burner
-
Usage:
-
car painting and baking
-
Ventilation system:
-
2 intake fans ,1 exhaust fan
-
Fan type:
-
centrifugal
-
Filtration system:
-
3 filters including environmental system
-
Certificate:
-
CE,ISO
-
Car spray booth:
-
electric heating
-
Environmental system:
-
3 layers activated carbon filter
Quick Details
-
Power:
-
Customized
-
External Size:
-
7000*5500*3300mm
-
Internal Size:
-
6900*3900*2650mm
-
Voltage:
-
380v/3phase/50hz
-
Disc Dia.:
-
non
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Qiangxin
-
Model Number:
-
QX2000
-
Warranty:
-
1 year, one year guarantee
-
Lighting System:
-
32 Pcs 18w LED energy saving lamps
-
Heating System:
-
RIELLO G20 diesel burner
-
Usage:
-
car painting and baking
-
Ventilation system:
-
2 intake fans ,1 exhaust fan
-
Fan type:
-
centrifugal
-
Filtration system:
-
3 filters including environmental system
-
Certificate:
-
CE,ISO
-
Car spray booth:
-
electric heating
-
Environmental system:
-
3 layers activated carbon filter
Advantage
1.professional factory with ISO certificate
2.good material with CE approval
3.infrared lamps qucik drying system
4.competitive factory price
5.Dust-free room for painting,good performance in baking
6.Micro-computer Programmed Controlling,touch screen
7.pre-sales service & after sale service
8.our products had sold to Germany,Norway,Nigeria,Egypt,Saudi Arabia,The United Arab
Emirates,Ethiopia,Qatar,Libya,Namibia,Cameroon,Ghana,Togo,Angola,Tanzania,Seychelles,Sudan,Philippine,Malaysia,Singapore,Australia,Russian Federation etc...
2.good material with CE approval
3.infrared lamps qucik drying system
4.competitive factory price
5.Dust-free room for painting,good performance in baking
6.Micro-computer Programmed Controlling,touch screen
7.pre-sales service & after sale service
8.our products had sold to Germany,Norway,Nigeria,Egypt,Saudi Arabia,The United Arab
Emirates,Ethiopia,Qatar,Libya,Namibia,Cameroon,Ghana,Togo,Angola,Tanzania,Seychelles,Sudan,Philippine,Malaysia,Singapore,Australia,Russian Federation etc...
Exported Countries
1.Our company applied the international leading design, advanced manufacture technology.
1.Our company applied the international leading design, advanced manufacture technology.
We provide the high-quality spraying equipments to the domestic and foreign clients.
2.Our products have been exported to Australia, Germany, Norway, Russian Federation,Singapore,Korea,etc.
2.Our products have been exported to Australia, Germany, Norway, Russian Federation,Singapore,Korea,etc.
Our service
Qiangxin Car Spray Booth Manufacturing factory assure every client who buy spray booths from us:
1. To meet demand of each client,providing spray booths according to client request
2. To provide good quality spray booths for cars,trucks and furniture
3. To guide every client assembly the spray booth after sales
4. 4. To help every client know well of the spray booth operation and maintenance
Qiangxin Car Spray Booth Manufacturing factory assure every client who buy spray booths from us:
1. To meet demand of each client,providing spray booths according to client request
2. To provide good quality spray booths for cars,trucks and furniture
3. To guide every client assembly the spray booth after sales
4. 4. To help every client know well of the spray booth operation and maintenance
Specification
|
Inside dimension
|
6900*3900*2650(mm)(L*W*H)
|
|
Outside dimension
|
7000*5500*3300(mm)(L*W*H)
|
|
Entrance door
|
Aluminum alloy binding framework(thickness:1.8mm),1 set folding door size:2830*2600(mm)(W*H)
|
|
Personal door
|
1 set side hung door:700*1700mm(W*H)
|
|
Wallboard
|
50mm EPS(epispastics polystyrene) insulation material with S=0.476 two side steel panel.
|
|
Lighting system
|
Lamp boxes are 45°fixed on upper two side, with 8 groups *4pcs =32pcs 18w energy saving LED lamps
|
|
Air intake and Exhaust system
|
With 2pcs centrifugal air blowers.Total parameter:YDW4.5AL1.2sets*4KW.25000m³/h
With 1pc centrifugal air blower, single parameter:YDW5.0A.5.5KW.15000m³/h |
|
Cabinet setting
|
Intake air from upside,downside exhaust wind.
Frame is made of tube:50*50mm,body plate is made of galvanized plate(thickness:0.8mm) (face the booth,the air cabinet is on the right side) |
|
Heating system
|
With 1pc RIELLO G20 diesel burner, 1pc stainless steel heat exchanger. 1pc actuator, 1pc fuel box. 1pc fuel box shelf. Maximum heat output 250000kcal/h.The operating temperature:50℃~60℃.Max temperature:80 ℃
|
|
Air duct
|
Made of galvanized plate,700*700*900. 2pcs straight,1pc elbow
|
|
Filtration system
|
4 filters:
1.Air inlet with prefilter. 2. Ceiling equipped with CC-G650 type high-efficiency filter,which can effectively filter the 5PM dust particles. 3. with 3 layers of activated carbon in exhaust fan cabinet. 4. With fiberglass filter in exhaust cabinet. |
|
Roof
|
Galvanized steel panel.
|
|
Basement
|
High performance antirust treatment grille galvanized (5 rows of grilles). Square tube column. 2 pcs antirust treatment ramps: 2000*630mm(L*W).
|
|
Control system
|
Painting, baking, light switch, breakdown indicator, power switch, emergency stop switch
(Face the booth, the control system is on the right side) |
|
Voltage frequency
|
380V 50HZ 3 phase
|
|
Light intensity
|
≥1000luxes
|
|
Air flow speed
|
≥0.25m/s
|
|
Total power
|
14.5kw
|
Product Description
Heating system
Gas burner heating system
Lighting system
Lamp boxes are 45° fixed on upper two side, with 8
groups*4pcs =32pcs 18w energy saving LED lamps.
Filtration system
1.Air inlet with prefilter.
2.Ceiling equipped with CC-G650 type high-efficiency filter,which can effectively filter the 5PM dust particles.
2.Ceiling equipped with CC-G650 type high-efficiency filter,which can effectively filter the 5PM dust particles.
3.with 3 layers of activated carbon in exhaust fan cabinet.
4.With fiberglass filter in exhaust cabinet.
4.With fiberglass filter in exhaust cabinet.
Air intake and exhaust system
With 2pcs centrifugal air blowers. Total parameter: YDW4.5AL1.2sets*4KW.25000m³/h
With 1pc centrifugal air blower, single parameter: YDW5.0A.5.5KW.15000m³/h
With 1pc centrifugal air blower, single parameter: YDW5.0A.5.5KW.15000m³/h
Wallboard
50mm EPS(epispastics polystyrene) insulation material with S=0.476 two side steel panel.
