Quick Details
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KERRY
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1600*650*2000mm
-
Hollow part volume:
-
100ml - 20L
-
Weight (KG):
-
1500 KG
-
Automatic:
-
semi - automatic
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Material:
-
SUS304 of Semi-automatic Bottle Blowing Machine
-
Product name:
-
Semi-automatic Bottle Blowing Machine
-
Type:
-
Semi-automatic of Bottle Blowing Machine
-
Output:
-
800-1000pcs/h of Semi-automatic Bottle Blowing Machine
-
Raw material:
-
PET Raw Material
-
Model Number:
-
KM-2C
-
Weight:
-
600KG
-
Power:
-
11KW
Quick Details
-
Neck Diameter(mm):
-
100 mm
-
Max.Bottle Diameter(mm):
-
100 mm
-
Max.Bottle Height(mm):
-
3300 mm
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KERRY
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1600*650*2000mm
-
Hollow part volume:
-
100ml - 20L
-
Weight (KG):
-
1500 KG
-
Automatic:
-
semi - automatic
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Material:
-
SUS304 of Semi-automatic Bottle Blowing Machine
-
Product name:
-
Semi-automatic Bottle Blowing Machine
-
Type:
-
Semi-automatic of Bottle Blowing Machine
-
Output:
-
800-1000pcs/h of Semi-automatic Bottle Blowing Machine
-
Raw material:
-
PET Raw Material
-
Model Number:
-
KM-2C
-
Weight:
-
600KG
-
Power:
-
11KW
Semi automatic bottle blowing machine adopt special electronic controlling circuit for heating, high efficiency in simultaneous controlling one lamp or more, lower powder consumption.
This machine can blow plastic bottle for water, juice, oil, carbonated drinks and so on. One drying tunnel is matched with two blowers, which is small in size, productive and energy saving, and fit to blow plastic bottles of various raw material in big quantity.
Application:
It is use for water bottle, beverage bottle, juice bottle, round bottle, square bottle, flat bottle, barrel and other bottle or container blowing.
Technical Parameters:
|
Model |
KM-1C |
KMB-2C |
KMB-4C |
|
Output (B/H) |
500 |
900 |
1800 |
|
Number of cavities |
1 |
2 |
4 |
|
Max bottle height |
360 |
360 |
360 |
|
Max bottle diameter |
120 |
110 |
110 |
|
Voltage |
220-380V/50-60HZ |
220-380V/50-60HZ |
220-380V/50-60HZ |
|
Total power |
11 |
11 |
21 |
|
Heating power |
10 |
10 |
20 |
|
Main body dimension (LxWxH) |
1.6x0.65x2.0 |
1.5x0.65x2.0 |
1.5x0.65x2.0 |
|
Main body weight |
600 |
550 |
550 |
|
Pre-heater size (LxWxH) |
1.4x0.6x1.4 |
1.4x0.6x1.4 |
1.8x0.6x1.4 |
|
Pre-heater weight |
300 |
300 |
350 |
Remarks:
If customer have special requirement, we can made according to customer requirement.
We supply over sea technical service.
1.Efficience and convenient conmunication with tools online, e-mail and telephone.
2.The equipment we sell all have one year warranty.
3.We have advanced techincal engeinner to provide reliable after-sales service.
4.We assist to install machine freely, and we are in charge of adjustment.
5.We have many skillful technicians and we can provide professionl maintenance service.
