2W series small oriffice Fluid Control Valve, also known zero-pressure solenoid valve, the initial state for normally closed,normally open only available for below 3/8", thread size range from 1/8" to 3/8", Din connector type and flying leads type,anti-explosion and anti-water coil are available. With the stalbe quality and wide application, 2W valve is popular with
customers, especially in the water treatment system, the 2W valve is used widely.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
2W160-15
-
Brand Name:
-
VPC
-
Body Material:
-
brass
-
Working Terperature:
-
-5~80℃
-
Pressure:
-
200Psi
-
Acting Type:
-
direct acting
-
Certificate:
-
CE RoHS ISO9001
Quick Details
-
Port Size:
-
1/2"
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
2W160-15
-
Brand Name:
-
VPC
-
Body Material:
-
brass
-
Working Terperature:
-
-5~80℃
-
Pressure:
-
200Psi
-
Acting Type:
-
direct acting
-
Certificate:
-
CE RoHS ISO9001
1/2" NPT 12V solenoid valve for air ride suspension system
|
Model
|
2W160-10
|
2W160-15
|
2W200-20
|
2W250-25
|
2W350-35
|
2W400-40
|
2W500-50
|
||||||
|
Working Medium
|
Air、Water、Oil、Gas
|
|
|
|
|
|
|
||||||
|
Acting Type
|
Direc Acting Type
|
|
|
|
|
|
|
||||||
|
Control Style
|
Normal Close/Normal Open
|
|
|
|
|
|
|
||||||
|
Orifice
|
16mm
|
|
20mm
|
25mm
|
35mm
|
40mm
|
50mm
|
||||||
|
CV Value
|
4.8
|
|
7.6
|
12
|
24
|
29
|
48
|
||||||
|
Joint Size
|
G3/8"
|
G1/2"
|
G3/4"
|
G1"
|
G1
1
/4"
|
G1
1
/2"
|
G2"
|
||||||
|
Working Pressure
|
Air:0~0.7Mpa ; Water:0~0.5Mpa ; Oil:0~0.5Mpa; Gas:0~0.7Mpa
|
|
|
Air、Water、Oil:0~2.0Mpa
|
|
|
|
||||||
|
Max.Pressure
|
1.05Mpa
|
|
|
3.5Mpa
|
|
|
|
||||||
|
Working Temperature
|
-5~80℃（The temperature can reach -5~150℃ if change the seal）
|
|
|
|
|
|
|
||||||
|
Valve Body
|
Brass
|
|
|
|
|
|
|
||||||
|
Seal material
|
NBR、VITON
|
|
|
|
|
|
|
||||||
Ordering Code
2W(UW) Series 2/2 Direct Acting Solenoid Valve(Big Orifice)
2W 160 - 15 F D
□
AC110V
2W
→Type Code
2W:Direction
Solenoid Valve
160
→
Orifice
160:16mm 200:20mm
250:25mm 300:30mm
350:35mm 400:40mm
500:50mm
15→Joint Size
10:3/8" 15:1/2"
10:3/8" 15:1/2"
20:3/4" 25:1"
35:11/4" 40:11/2"
50:2"
F
→
Mounting Type
Blank:Standard
F:With Flange
D→
Coil Type
Blank:Flying leads
D:DIN Type
E:Anti-explosion Coil
G:Water-Proof Coil
□
→
Control Style
Blank:Normal Close
T:Normal Open
AC110V→Standard Voltage
DC12V
DC24V
AC24V 50/60H
Z
AC110V 50/60H
Z
AC220V 50/60H
Z
AC380V 50/60H
Z
Note:Only 2W160、2W200、2W250 valve can make normal open type
