Quick Details
-
Load chain::
-
G80
-
Capacity::
-
0.5-20t
-
Lifting height::
-
1.5M-10M
-
Color::
-
Black, Yellow, Orange, White, Blue
-
Brand Name:
-
OEM
-
Chain painting::
-
Galvanzied or Black coating
-
Application::
-
Industrial Lifting
-
Package::
-
Carton and wooden box
-
transport::
-
Shipping
Quick Details
-
Model Number:
-
VT
-
Place of Origin:
-
China
-
Product name::
-
Hand Chain Block
-
Load chain::
-
G80
-
Capacity::
-
0.5-20t
-
Lifting height::
-
1.5M-10M
-
Color::
-
Black, Yellow, Orange, White, Blue
-
Brand Name:
-
OEM
-
Chain painting::
-
Galvanzied or Black coating
-
Application::
-
Industrial Lifting
-
Package::
-
Carton and wooden box
-
transport::
-
Shipping
Vital 5 ton hoist hand chain block
Model: VT
1. One of beat selling hoist
2. Capacity ranges from 0.5t to 20t, heavy duty 30t,50t is available
3. Heavy duty and compact design to meet all pertinent work standard
4. Reliable disc brake, premium grade alloy load chain and zinc plated hand chain as standard
5. Drop-forged and expertly heat treated hooks for great strength and long wearing
Technical Benefits
1. Light weight robust construction;
2. Low effort to lift maximum load;
3. Fully forged hooks;
4. Fully machines lift wheel;
5. ISO high grade alloy chain;
6. Zinc plated hand chain as standard;
7. Double cover protection;
8. Durable baked enamel paint protection;
9. Overload protection device available upon request.
|
Product code |
Capacity (t) |
Standard lift (m) |
Test load (t) |
Pulling Efforts (kg) |
Chain fall No. |
Load chain Dia (mm) |
Dimensions(mm) |
Net Weight (kg) |
|||
|
A |
B |
C |
D |
||||||||
|
VT005 |
0.5 |
3.0 |
0.75 |
16 |
1 |
5.0 |
127 |
144 |
285 |
27 |
9.1 |
|
VT010 |
1.0 |
3.0 |
1.50 |
24 |
1 |
6.3 |
147 |
157 |
315 |
30 |
12.0 |
|
VT015 |
1.5 |
3.0 |
2.25 |
28 |
1 |
7.1 |
179 |
174 |
340 |
34 |
13.8 |
|
VT020 |
2.0 |
3.0 |
3.00 |
32 |
1 |
8.0 |
179 |
204 |
380 |
37 |
21.6 |
|
VT020A |
2.0 |
3.0 |
3.00 |
30 |
2 |
6.3 |
147 |
174 |
380 |
37 |
20.4 |
|
VT030 |
3.0 |
3.0 |
4.50 |
32 |
2 |
7.1 |
179 |
206 |
475 |
43 |
21.0 |
|
VT050 |
5.0 |
3.0 |
6.30 |
36 |
2 |
9.0 |
179 |
263 |
635 |
46 |
37.5 |
|
VT100 |
10.0 |
3.0 |
12.50 |
38 |
4 |
9.0 |
179 |
367 |
760 |
67 |
59.5 |
|
VT150 |
15.0 |
5.0 |
18.80 |
38x2 |
6 |
9.0 |
207 |
754 |
850 |
84 |
125.0 |
|
VT200 |
20.0 |
5.0 |
25.00 |
38x2 |
8 |
9.0 |
207 |
873 |
870 |
96 |
145.6 |
