Quick Details
-
Warranty:
-
25 years wanrranty
-
Brand Name:
-
Longi
-
Model Number:
-
HI-MO 7 LR5-72HGD
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Solar cell:
-
182*91mm Mono
-
Solar panel:
-
560w-590w
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm ^2 300mm PV Cable
-
Weight:
-
31.8KG
-
Connector:
-
MC4 Compatible Connector
-
Product name:
-
Half Cell Monocrystalline Solar Panel
-
Operate Temperature:
-
-40~+85°C
-
Certificate:
-
TUV CE ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, N-TYPE
-
Panel Efficiency:
-
22.8%
-
Warranty:
-
25 years wanrranty
-
Brand Name:
-
Longi
-
Model Number:
-
HI-MO 7 LR5-72HGD
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Solar cell:
-
182*91mm Mono
-
Solar panel:
-
560w-590w
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm ^2 300mm PV Cable
-
Weight:
-
31.8KG
-
Connector:
-
MC4 Compatible Connector
-
Product name:
-
Half Cell Monocrystalline Solar Panel
-
Operate Temperature:
-
-40~+85°C
-
Certificate:
-
TUV CE ISO
Product Description
Specification
|
Brand Name
|
Longi
|
|
Model Number
|
HI-MO 7 LR5-72HGD
|
|
Place of Origin
|
China
|
|
|
Anhui
|
|
Cell size
|
182mmx182mm
|
|
Type
|
PERC, Half Cell, Bifacial,
|
|
Panel Dimensions
|
2278X1134x30mm
|
|
Panel Efficiency
|
22.8%
|
|
Warranty
|
25 years wanrranty
|
|
Solar cell
|
182*91mm Mono
|
|
Solar panel
|
560-580W
|
|
Junction Box
|
IP68 Rated
|
|
Glass
|
3.2mm Tempered Low Iron
|
|
Frame
|
Anodized Aluminium Alloy
|
|
Cable
|
4mm ^2 300mm PV Cable
|
|
Weight
|
30.8KG
|
|
Connector
|
MC4 Compatible Connector
|
|
Product name
|
Half Cell Monocrystalline Solar Panel
|
|
Certificate
|
TUV CE ISO
|
|
Electrical Characteristics STC:AM1.5 1000W/m²25℃ NOCT:AM1.5 800W/m² 20℃ 1r .m/s
|
STC:AM1.5 1000W/m²25℃
|
NOCT:AM1.5 800W/m² 20℃ 1r .m/s
|
Test uncertainty for Pmax: ±3%
|
|
||||
|
Module Type
|
HI-MO 7 LR5-72HGD 560M
|
HI-MO 7 LR5-72HGD 570M
|
HI-MO 7 LR5 72HGD 580M
|
HI-MO 7 LR5-72HGD590M
|
||||
|
Testing Condition
|
STC NOCT
|
STC NOCT
|
STC NOCT
|
STC NOCT
|
||||
|
Maximum Power(Pmax/W)
|
560 426
|
570 434
|
580 441
|
590 449
|
||||
|
Open Circuit Voltage(Voc/M)
|
38.53 36.18
|
38.73 36.36
|
38.93 36.55
|
39.13 36.74
|
||||
|
Short Circuit Current(lsc/A)
|
13.92 11.24
|
14.00 11.31
|
14.07 11.36
|
14.15 11.43
|
||||
|
Voltage at Maximum Power (VmpM)
|
32.24 29.42
|
32.44 29.60
|
32.64 29.78
|
32.84 29.97
|
||||
|
Current at Maximum Power (Imp/A)
|
12.88 10.54
|
12.95 10.60
|
13.03 10.67
|
13.10 10.72
|
||||
|
Module Efficiency(%)
|
21.3
|
21.5
|
21.8
|
22.0
|
||||
|
Test uncertainty for Pmax: ±3%
|
|
|
|
|
||||
