Quick Details
-
Screen Size:
-
14 inch, 14.1 inch
-
CPU:
-
J4125 2.0GHz/RK3288/RK3568, J4125/1900/i3/i5/RK3288/RK3568
-
Resolution:
-
1920*1080 pixel, 1920*1080 pixel
-
SSD:
-
64G
-
Operation System:
-
Android or Windows
-
Place of Origin:
-
Guangdong, China
-
Built-in Printer:
-
80mm printer
-
Print speed:
-
160mm/sec
-
Printer paper width:
-
80*70mm
-
Interface:
-
USB*5,RS232*1.RJ45*1,RJ11*1
-
Optional:
-
2D barcode scanner,7/10.1"LCD Display
-
Printer Mode:
-
Receipt/Label Printer
-
Size:
-
335mm(L)*238mm(W)*339mm(H)
Quick Details
-
Model Number:
-
FYJ-F2
-
Country of Origin:
-
China
-
Brand Name:
-
Feng Yi Jie
-
Screen Size:
-
14 inch, 14.1 inch
-
CPU:
-
J4125 2.0GHz/RK3288/RK3568, J4125/1900/i3/i5/RK3288/RK3568
-
Resolution:
-
1920*1080 pixel, 1920*1080 pixel
-
SSD:
-
64G
-
Operation System:
-
Android or Windows
-
Place of Origin:
-
Guangdong, China
-
Built-in Printer:
-
80mm printer
-
Print speed:
-
160mm/sec
-
Printer paper width:
-
80*70mm
-
Interface:
-
USB*5,RS232*1.RJ45*1,RJ11*1
-
Optional:
-
2D barcode scanner,7/10.1"LCD Display
-
Printer Mode:
-
Receipt/Label Printer
-
Size:
-
335mm(L)*238mm(W)*339mm(H)
Products Description
|
F2A
|
|
|
F2W
|
|
|
||||
|
Features
|
CHARACTERISTICS
1. Google service D2A android POS with google playstore GMS 2. Multiple connect port. RS232 for weight scale,HDMI for display monitor. 3. D2A POS with 5 USB-C for proprietary peripherals Consolidate peripheral integrations for attended and unattended applications 4. Multiple CPU options Rockchip RK3288/ RK3568 configurations: keep consistent look and feel across your business environment 5. Multiple operating systems Compatible in both Android 8.1 & Android 11. 6. Cable management Easily hide cables in the base for a clean installation 7. Inbuilt 80MM thermal Printer Commands support: ESC/POS /OPOS Driver, interface USB/RS232/ bluetooth. Support thermal receipt & thermal Label. Load paper size 80*70mm , Printing speed: 200mm/sec,Cash drawer: (9-24V ) |
|
Features
|
1. Field upgradeable Quickly upgradeable RAM and SSD to increase system specifications 2. Optional Wi-Fi® antenna No need for cabling - easily upgrade to high speed wireless access 3. D2 POS with 5 USB-C for proprietary peripherals Consolidate peripheral integrations for attended and unattended applications 4. Multiple CPU options Celeron® and intel i3 /i5 /i7 configurations: keep consistent look and feel across your business environment 5. Multiple operating systems Compatible in both Windows 10 IoT, Windows 10 PRO , and Linux 6. Cable management Easily hide cables in the base for a clean installation 7. Inbuilt 80MM thermal Printer Commands support: ESC/POS /OPOS Driver , interface USB/RS232/ bluetooth. Support thermal receipt & thermal Label. Load paper size 80*70mm , Printing speed: 200mm/sec Cash drawer: (9-24V ) |
|
||||
|
OS
|
Android RK3288
|
Android RK3568
|
OS
|
Windows J4125
|
Windows J6412
|
||||
|
Processor
|
RK3288 , Quad core A17, 1.8GHz
|
RK3568 Quad-core Cortex-A55 up to 2.0GHz
|
Processor
|
Celeron® J41254M Cache,up to 2.70 GHz
|
Celeron® J6412 1.5M Cache, up to 2.60 GHz
|
||||
|
Memory
|
DDR3 -2GB, Max 4GB
|
DDR4 -2GB,Max 4GB
|
Memory
|
1 x SO-DIMM, DDR4,2GBUp to 8GB
|
1 x SO-DIMM, DDR42GBUp to 16GB
|
||||
|
Storage
|
ROM 16G(default) 32G/ 64GB
|
|
Storage
|
MSATASSD,64G(default ), 128G/256G/512GB
|
|
||||
|
Printer
|
80mm Thermalprinter with Auotutter
Support thermal receipt &thermal sticker Commands: ESC/POS,OPOSdriver Paper size: 80*70mm |
|
Printer
|
80mm Thermalprinter with Auotutter
support thermal receipt &thermal sticker commands: ESC/POS,OPOSdriver Paper size: 80*70mm |
|
||||
|
I/O
|
USB5, (3.0*2, 2.0*2, OTG *1 )
Serial port: UART x 1 RJ11 x 1 LAN: RJ45x 1 TF slot* 1 SIM slot* 1 Audio* 1 |
USB5, (3.0*2, 2.0*2, OTG *1 )
HDMI *1 LAN: RJ45x 1 TF slot* 1 SIM slot* 1 Audio* 1 RS232* 2 |
I/O
|
USB5, (3.0 x 2, 2.0 x 3)
Serial ports: RS232x 1 Display: VGA x 1 up to 1920x1080 LAN: RJ45x 1 Cash Drawer: RJ11x 1 AUDIO* 1 |
|
||||
|
Display
|
14" IPS (BOEbrand )
|
|
Display
|
14" IPS (BOEbrand )
|
|
||||
|
Brightness
|
250 NITS
|
|
Brightness
|
250 NITS
|
|
||||
|
Resolution
|
1920*1080
|
|
Resolution
|
1920*1080
|
|
||||
|
Speaker
|
1*3W (Optional)
|
|
Speaker
|
1*3W (Optional )
|
|
||||
|
Touch screen
|
True Flat Capacitive Touch
|
|
Touch screen
|
True Flat Capacitive Touch
|
|
||||
|
Wi-Fi
|
2.4G
|
2.4G/5G
|
Expansion
|
M 2 EKey for Wi-Fi® /Bluetooth® (Module optional) MiniPCle
|
|
||||
|
Bluetooth
|
BT3.0/BT4.0 /4.2/BLE
|
BT3.0/BT4.0 /4.2/BLE
|
LAN
|
1×RJ45 1000M
|
|
||||
|
LAN
|
1×RJ45WLAN 802.11a/b/g/n/ac/ 1000M
|
|
Wireless
|
1 x WLAN 802.11a/b/g/n/ac + Bluetooth® 4.2/ BLE(Optional)
|
|
||||
|
4G
|
4G module (optional)
|
|
OS Windows
|
Windows® 10 IOT，Windows® 10 PRO ,Linux
|
|
||||
|
OS
|
Android 7.1/ 8.1
|
Android 11
|
Power adaptor
|
Device: 84W/12 V DCJackAdapter
Power supply: from 100Vacto 240Vac |
|
||||
|
Power adaptor
|
Device: 84W/12 V DCJackAdapter
Power supply: from 100Vacto 240Vac |
|
Dimensions
|
335mm(L)*238mm(W)*339mm(H)
|
|
||||
|
Dimensions
|
335mm(L)*238mm(W)*339mm(H)
|
|
Weight
|
5.9KG
|
|
||||
|
Weight
|
4.5 KG
|
|
OPTIONAL ACCESSORIES
|
Second display 10.1” IPS (1280*800)
Second display 7” IPS (1024*600) 2D Barcode Scanner (inbuilt) NFC Card Reader |
|
||||
|
OPTIONAL ACCESSORIES
|
Second display 10.1” IPS (1280*800)
Second display 7” IPS (1024*600) 2D Barcode Scanner (inbuilt) NFC Card Reader |
|
Model
|
Windows® - J4125 4GB/128GB SSD - 16:9 (14")
Windows® - i3 3217U 8GB/256GB SSD - 16:9 (14") Windows® - i5 4210U 8GB/256GB SSD - 16:9 (14") Windows® - i7 6500U 8GB/256GB SSD - 16:9 (14") Windows® - J6412 4GB/128GB SSD - 16:9 (14") |
|
||||
|
Model
|
Android 8.1 - RK3288 2GB/ 16GB - 16:9 (14")
Android 11 - RK3568 2GB/ 16GB - 16:9 (14") |
|
|
|
|
||||
