Quick Details
-
Place of Origin:
-
Guangdong, China
-
Commutation Structure:
-
interior Rotor Without Sensor
-
Function:
-
Driving
-
Speed:
-
23000rpm
-
Phase:
-
3 Phase
-
Applications:
-
mini household appliance
-
Length:
-
20mm
-
Diameter:
-
12mm
-
Rated Voltage:
-
7.4v
-
Motor type:
-
DC Brushless Three Phase
-
Weight:
-
9.5g
Quick Details
-
Speed(RPM):
-
23000rpm
-
Continuous Current(A):
-
0.8A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Guangdong, China
-
Commutation Structure:
-
interior Rotor Without Sensor
-
Function:
-
Driving
-
Speed:
-
23000rpm
-
Phase:
-
3 Phase
-
Applications:
-
mini household appliance
-
Length:
-
20mm
-
Diameter:
-
12mm
-
Rated Voltage:
-
7.4v
-
Motor type:
-
DC Brushless Three Phase
-
Weight:
-
9.5g
1220-3100KV RC boat car mini EDF helicopter brushless motor inrunner
| CONSTAR MICROMOTOR | ||
|
|
|
| PRECISION DC CORELESS MOTOR | BRUSHLESS DC MOTOR | SERVO MOTOR |
|
||
| GEARMOTOR | STEP MOTOR | MINI CORELESS MOTOR |
1. Applications: Medical equipment, industrial equipment, navigation models, electricaltools and mini household appliances
2. Operating Environment: -40~+100°C
3. Characteristics :
...
|
Series |
Performance Code |
Dimension
|
Voltage ( V ) |
No-load
Speed
|
No-load
|
Load
|
Load Speed
|
Load Current
|
KV
Value
|
|
1220ZWWN |
-3 |
Φ12*20 |
7.4 |
23000 |
100 |
0.98 |
19600 |
450 |
3100 |
4. Options: Lead wires length, shaft length, special coils, gearheads,bearing type, driver,encoder
| Series |
Dimension
(mm) |
Voltage
(V) |
No-load Speed
(rpm) |
No-Load Current
(mA) |
KV Value
(rpm/V) |
Torque Constant
(mNm/A) |
|---|---|---|---|---|---|---|
| 1215ZWWN | Φ12*15 | 3.6 | 35000 | 300 | 9720 | 0.93 |
| Φ12*15 | 4.5 | 14500 | 100 | 3220 | 2.62 | |
| Φ12*15 | 7.4 | 42500 | 200 | 5470 | 1.55 | |
| 1220ZWWN | Φ12*20 | 5 | 17500 | 210 | 3500 | 2.5 |
| Φ12*20 | 6 | 17200 | 150 | 2900 | 3.0 | |
| Φ12*20 | 7.4 | 23000 | 100 | 3100 | 2.9 | |
| 1230ZWWN | Φ12*30 | 3.7 | 18000 | 230 | 4860 | 1.9 |
| Φ12*30 | 9 | 18000 | 150 | 2000 | 4.6 | |
| Φ12*30 | 12 | 11500 | 50 | 960 | 9.6 | |
| 1329ZWWN | Φ13*29 | 12 | 25000 | 100 | 2100 | 4.3 |
| 1635ZWWN | Φ16*35 | 12 | 45000 | 350 | 3750 | 2.5 |
| 2030ZWWN | Φ20*30 | 12 | 43300 | 370 | 3600 | 2.6 |
| Φ20*30 | 12 | 7000 | 100 | 580 | 14.9 | |
| Φ20*30 | 12 | 9200 | 250 | 770 | 11 | |
| 2040ZWWN | Φ20*40 | 9 | 6700 | 200 | 745 | 12.1 |
| Φ20*40 | 12 | 15000 | 250 | 1250 | 7.5 | |
| Φ20*40 | 12 | 8000 | 360 | 670 | 13.4 | |
| 2050ZWWN | Φ20*50 | 12 | 6000 | 160 | 500 | 18 |
Customized Motor Solutions
CONSTAR MICROMOTOR specialize in design, custom and manufacture electric motors,including DC Coreless Motor , Sonic Motor , Brushless DC Motor , Gear Motor , Servo Motor , DC Core Motor and Mini Step Motor. All of them can be fully and easily customized . We committed to offer high quality, high performance, cost effective options to meet customers specific demands. Choosing to customize one of the motors in our Product Categories now!
