Quick Details
-
Dimension(L*W*H):
-
according to different mode
-
Product Name:
-
electromagnet pulling 12 volt 24v 380v small powerful electromagnet
-
Rated Voltage:
-
DC-220v
-
Shape:
-
rectangle, square, circular, round, oval, ellipse, oblong
-
Type:
-
normal, high temperature , (super) high Frequency, strong magnet type.
-
Color:
-
yellow, blue, white, red, green, purple, black or as your requirement
-
Composite::
-
Aluminum Coil, steel plate, magnetic wire
-
Usage:
-
lifting steel scraps, billet, slab, coiled bar, steel pipe, etc.
-
Application:
-
Crane Transport, mine, metallurgy, coal, construction materials. etc.
-
market:
-
Hot sale, Africa, Asian, South America, Europe, all over the world
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Certification:
-
CCC, CE, ISO9001
Quick Details
-
Warranty:
-
One Year
-
Place of Origin:
-
China
-
Brand Name:
-
HENGTAI
-
Dimension(L*W*H):
-
according to different mode
-
Product Name:
-
electromagnet pulling 12 volt 24v 380v small powerful electromagnet
-
Rated Voltage:
-
DC-220v
-
Shape:
-
rectangle, square, circular, round, oval, ellipse, oblong
-
Type:
-
normal, high temperature , (super) high Frequency, strong magnet type.
-
Color:
-
yellow, blue, white, red, green, purple, black or as your requirement
-
Composite::
-
Aluminum Coil, steel plate, magnetic wire
-
Usage:
-
lifting steel scraps, billet, slab, coiled bar, steel pipe, etc.
-
Application:
-
Crane Transport, mine, metallurgy, coal, construction materials. etc.
-
market:
-
Hot sale, Africa, Asian, South America, Europe, all over the world
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Certification:
-
CCC, CE, ISO9001
product description
Circular Lifting Magnet can handle tones of scrap continuously throughout the day. they can lift steel more quickly and conveniently than any other mechanical device. Suitable for transferring cast ingots, steel balls, metal and steel scraps.
Features:
1, the use of fully closed structure, good moisture-proof performance.
2, through the computer optimization design, reasonable structure, absorption ratio, low energy consumption.
3. The special process of the excitation coil improves the electrical and mechanical properties of the coil, and the heat-resistant grade of the insulation material reaches grade C, with a long service life.
4. Different structures and parameters are adopted for different absorbent conditions, which can widely meet the needs of users.
5, high temperature electromagnet with a unique way of heat insulation, the absorbed temperature from the past 600℃ to 700℃, expanding the scope of application of electromagnet.
6. Simple installation, operation and maintenance.
Considerations for type selection:
1. When the temperature of the suction and transport materials is lower than 100℃, please choose the normal temperature type; when the temperature exceeds 100℃, please choose the high temperature type.Please specify above 600℃.
2. Please choose high frequency when the power supply duration exceeds 60%.
3. Please choose submersible type (submersible depth is less than 100 meters) for water suction and hoisting materials. The parameters of submersible type electromagnet are the same as that of normal temperature type.If the user needs the diving type, please specify when ordering.
4. Supporting equipment;When a single unit is used, the rectifier control equipment and auxiliary equipment are selected according to the consumed power (current). When multiple units are used together, the rectifier control equipment and auxiliary equipment are selected according to the sum of the consumed power (current) of the number of connected units.
Main techincal data
|
Model |
Current in cold state ( A) |
Power in cold state (KW) |
Lifting capacity (kg) |
Weight (kg) |
Overall dimension (mm) |
Control Equip ment |
Cable reel & Cable Conne ctor |
||||||
|
Single steel ball |
Packed steel ingots |
Packed steel scraps |
A |
B |
C |
D |
E |
||||||
|
MW5-70L/1 |
15 |
3.3 |
2500 |
380/200 |
120/100 |
490 |
700 |
800 |
160 |
90 |
30 |
STML-4E-C |
JTA75-15-2 DL-102 |
|
MW5-80L/1 |
18 |
3.96 |
3000 |
480/250 |
150/130 |
620 |
800 |
800 |
160 |
90 |
30 |
STML-4E-C |
|
|
MW5-90L/1 |
26.6 |
5.85 |
4500 |
600/400 |
250/200 |
800 |
900 |
1090 |
200 |
125 |
40 |
STQL-7E-C |
|
|
MW5-110L/1 |
35 |
7.7 |
6500 |
1000/800 |
450/400 |
1350 |
1100 |
1140 |
220 |
150 |
45 |
STQL-9E-C |
JTA100-15-2 DL-102 |
|
MW5-120L/1 |
45.5 |
10 |
7500 |
1300/1000 |
600/500 |
1700 |
1200 |
1180 |
220 |
150 |
45 |
STQL-14E-C |
|
|
MW5-130L/1 |
54 |
11.9 |
8500 |
1400/1100 |
700/600 |
2060 |
1300 |
1240 |
250 |
175 |
50 |
STQL-14E-C |
|
|
MW5-150L/1 |
71.2 |
15.6 |
11000 |
1900/1500 |
1100/900 |
2830 |
1500 |
1250 |
350 |
210 |
60 |
STQL-19E-C |
|
|
MW5-165L/1 |
75 |
16.5 |
12500 |
2300/1800 |
1300/1100 |
3200 |
1650 |
1590 |
370 |
230 |
75 |
STQL-19E-C |
|
|
MW5-180L/1 |
102.4 |
22.5 |
14500 |
2750/2100 |
1600/1350 |
4230 |
1800 |
1490 |
370 |
230 |
75 |
STQL-25E-C |
JTA200-15-2 DL-202 |
|
MW5-210L/1 |
129 |
28.4 |
21000 |
3500/2800 |
2200/1850 |
7000 |
2100 |
1860 |
400 |
250 |
80 |
STQL-32E-C |
|
|
MW5-240L/1 |
154 |
33.9 |
26000 |
4800/3800 |
2850/2250 |
9000 |
2400 |
2020 |
450 |
280 |
90 |
STQL-38E-C |
|
Precautions for use:
1. Check whether there is any damage to the parts of the electromagnetic chuck before use and replace them as soon as possible
2. Pay attention to the surroundings before lifting, and do not pass over the equipment and personnel
3. Check whether the rated current is reached before lifting.
4. Before lifting, pay attention to check whether there are non-conductive magnetic items between the lifting object and the lifting electromagnetic chuck to avoid affecting the lifting height
5, the lifting electromagnetic suction must be placed on the top of the sucked items, and then electrified, so as not to appear small iron cutting
6, when landing must pay attention to observe the surrounding environment, pay attention to safety.
Packing & Delivery
Export packing
1.Control cabinet is packed by wooden box ,crane lifting electromagnet is packed by plastic
2.Wood case for electric parts, accessories;large sections will be loaded onto bulk cargo ship after packing.
Convenient transportation:
1.All available modes of transport can be express, air or sea.
2.The nominated shipping company or our own forwarder can be used for shipment.
3.Track the goods for you until the goods arrive.
4.Shipping time: 20-30 days after receive the deposit.
Our company
Henan Armagh co., LTD. By virtue of scientific management system, convenient transportation conditions, strong production capacity, advanced detection means and strong sales network, to produce high quality, beautiful appearance lifting products to serve large and medium-sized enterprises at home and abroad.Company has a sound quality assurance system closely, the product research and development, design, manufacture, process, quality inspection, after-sales service and other links are covered in the quality assurance system under the control of, in the elaboration structure, energy conservation, environmental protection, safe and reliable, to adopt new technology of new materials and other aspects, make the product quality level enhances unceasingly, product marketing all over the world.
Certifications
FAQ
1. Q: Are you a trading company or a factory?
A: We are factory which has a lot of experience.
2. Q: Do you accept special design?
A: Yes, we can design and manufacture products according to client's special requirements.
3. Q: What about your package?
A: We use wooden box as normal, but if you have special requirement we can change and add special shipping mark.
4. Q: How long will you take before shipping?
A: It is according to the products you need.
