Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
GQ Seriese
-
Mounting Hole Size:
-
12mm/16mm/19mm/22mm/25mm/30mm
-
Head type:
-
High round/ flat round/ High round /Custom
-
Material:
-
Stainless Steel / Aluminium Alloy
-
Function:
-
1NO1NC/2NO2NC
-
LED color:
-
Red.Yellow.Green.White.Blue.Orange. Double color. Tri-color
-
Operation type:
-
Momentary/Latching/Delayed
-
Certification:
-
CE RoHS REACH CCC
Quick Details
-
Protection Level:
-
IP65/IP67
-
Max. Current:
-
5A
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
GQ Seriese
-
Mounting Hole Size:
-
12mm/16mm/19mm/22mm/25mm/30mm
-
Head type:
-
High round/ flat round/ High round /Custom
-
Material:
-
Stainless Steel / Aluminium Alloy
-
Function:
-
1NO1NC/2NO2NC
-
LED color:
-
Red.Yellow.Green.White.Blue.Orange. Double color. Tri-color
-
Operation type:
-
Momentary/Latching/Delayed
-
Certification:
-
CE RoHS REACH CCC
|
Brand
|
ONPOW
|
|
Mounting hole
|
8mm,10mm,12mm,16mm，22mm,25mm,28mm,30mm,40mm
|
|
Contact
|
1NO1NC,2NO2NC,etc
|
|
Operation type
|
Momentary/latching
|
|
LED color
|
R/G/B/W/O/Y/etc
|
|
LED voltage
|
6V,12V,24V other voltage could be customized
|
|
Terminal type
|
Pin terminal/Screw terminal
|
|
Housing material
|
Stainless steel/Aluminum Alloy/etc
|
|
Button material
|
Stainless steel/Aluminum Alloy/etc
|
|
Mechanical life
|
1000,000 cycles
|
|
Electronical life
|
50,000 cycles
|
|
Protection level
|
IP65/IP67
|
|
|
|
