Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
AME
-
Voltage:
-
220V /50 hz
-
Dimension(L*W*H):
-
l650*w555*h900mm
-
Weight:
-
180 kg
-
Warranty:
-
1 year
-
Marketing Type:
-
Hot Product 2022
-
PLC Brand:
-
other
-
product name:
-
electrode cutting machine
-
size:
-
Customizable
-
power supply:
-
220V /50 hz
-
compressed air:
-
0.5 Mpa to 0.8 Mpa
-
cut size:
-
300*300mm
-
tensile cylinder:
-
1.5T
-
pressure cylinder:
-
3Ton
-
cutting precision:
-
+ /- 0.1 mm
-
Max punching size:
-
L85*W65mm
-
Related industries:
-
Lithium ion battery
Quick Details
-
Type:
-
Die-cutting Machine
-
Production Capacity:
-
150 m/min
-
Max. workable width:
-
1000mm
-
Place of Origin:
-
China
-
Brand Name:
-
AME
-
Voltage:
-
220V /50 hz
-
Dimension(L*W*H):
-
l650*w555*h900mm
-
Weight:
-
180 kg
-
Warranty:
-
1 year
-
Marketing Type:
-
Hot Product 2022
-
PLC Brand:
-
other
-
product name:
-
electrode cutting machine
-
size:
-
Customizable
-
power supply:
-
220V /50 hz
-
compressed air:
-
0.5 Mpa to 0.8 Mpa
-
cut size:
-
300*300mm
-
tensile cylinder:
-
1.5T
-
pressure cylinder:
-
3Ton
-
cutting precision:
-
+ /- 0.1 mm
-
Max punching size:
-
L85*W65mm
-
Related industries:
-
Lithium ion battery
Laboratory Desktop Pouch Cell Semi-Automatic Electrode Die Cutter For Polymer Battery Research
|
Model |
Semi-auto Battery Electrode Die Cutter |
|
Stroke |
35mm |
|
Vertical burr |
≤12μm |
|
Horizontal burr |
≤20μm |
|
Punching accuracy |
±0.1mm |
|
feeding way |
manually |
|
Max punching size |
L85*W65mm Or customized according to requirements |
|
Punching pressure |
Max. 1T (0.5MPa compressed air) Punching the battery electrode recommended pressure 500Kg |
|
equipment production capacity |
800-2000 - ea/H die cutting efficiency is lower (sheet material) |
Semi-auto Battery Electrode Die Cutter Feature:
*
replacement of die cutter
is
convenient, quick, consumable (die cutter is life about 30000 times);
* manual and continuous feeding, automatic discharging, and can automatically separate waste;
* no quality defects such as burrs, off powder, indentation;
* between manual and automatic, high efficiency, 800-2000 / per hour;
* simple operation, safe and reliable, beautiful appearance, small size
.
