Quick Details
-
Battey type:
-
LiFePO4 battery Pack
-
Pack capacity:
-
8/12/40/60/120/150/250/300Ah
-
Dimension:
-
L151*W65*H95 mm
-
Weight:
-
1.5kg, 1.5
-
Designed life:
-
>3500 cycles
-
Operating temp:
-
-10℃ to 50℃
-
Warranty:
-
3years
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Battery Size:
-
8/12/40/60/120/150/250/300Ah
-
Certification:
-
CE,Rosh,Fcc,etc.
Quick Details
-
Brand Name:
-
Lipower
-
Model Number:
-
Pack
-
Place of Origin:
-
Guangdong, China
-
Battey type:
-
LiFePO4 battery Pack
-
Pack capacity:
-
8/12/40/60/120/150/250/300Ah
-
Dimension:
-
L151*W65*H95 mm
-
Weight:
-
1.5kg, 1.5
-
Designed life:
-
>3500 cycles
-
Operating temp:
-
-10℃ to 50℃
-
Warranty:
-
3years
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Battery Size:
-
8/12/40/60/120/150/250/300Ah
-
Certification:
-
CE,Rosh,Fcc,etc.
Battery pack hight capacity 8ah 100ah 400ah flashlight li-ion lithium titanate battery pack
Product Description
Specification
|
Battery type
|
LiFePO4
|
|
|
|
|
||||
|
Pack capacity
|
10Ah
|
60Ah
|
100Ah
|
250Ah
|
300Ah
|
||||
|
Dimension(mm)
|
L151*W98*H98
|
L198*W166*H170
|
L330*W172*H214
|
L525*W240*H220
|
L525*W270*H220
|
||||
|
Weight
|
1.5kg
|
6kg
|
13kg
|
30kg
|
35kg
|
||||
|
Internal Resistance
|
30≤mΩ
|
|
|
|
|
||||
|
Cycle Life
|
2000 Cycles @ 0.2C Charging/Discharging,Until 80% Capacity
|
|
|
|
|
||||
|
Self Discharge
|
≤3.5% per month at 25℃
|
|
|
|
|
||||
|
Charge Voltage
|
14.6±0.2V
|
|
|
|
|
||||
|
Charging Mode
|
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and
then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A |
|
|
|
|
||||
|
Charging Current
|
70A
|
|
|
|
|
||||
|
Max.Charging Current
|
100A
|
|
|
|
|
||||
|
Discharging Current
|
70A
|
|
|
|
|
||||
|
Max. Continuous Current
|
250A
|
|
|
|
|
||||
|
Max.Pulse Current
|
2000A(<1S）
|
|
|
|
|
||||
|
Discharging Cut-off Voltage
|
10.0
|
|
|
|
|
||||
|
Charge Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
|
|
||||
|
Discharge Temperature
|
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
|
|
|
|
|
||||
|
Storage Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
|
|
||||
|
Water Dust Resistance
|
IP55
|
|
|
|
|
||||
|
Cell & Format
|
IFR26700 N40,4S50P
|
|
|
|
|
||||
|
Casing
|
Plastic
|
|
|
|
|
||||
|
Terminal
|
M8
|
|
|
|
|
||||
Feature
|
★
Using the technology of lithium iron phosphate cell, superior safety,
thousands of cycles, 100%DOD, under normal conditions. |
|
|
|
|
||||
|
★
Built-in automatic protection for over-charge, over discharge, over
current and over temperature & low temperature protection. ◆Free of maintenance. |
|
|
|
|
||||
|
★Internal cell balancing.
|
|
|
|
|
||||
|
★
Lighter weight: About 40% ~50% of the weight of a comparable
lead acid battery. |
|
|
|
|
||||
|
★Can be charged using most standard lead-acid charges (set).
|
|
|
|
|
||||
|
★Wider temperature range:-20℃~60℃.
|
|
|
|
|
||||
|
★
Support for Series application expansion (up to 51.2V) and four in
parallel. |
|
|
|
|
||||
Details
Application
|
★UPS.
|
|
|
|
|
||||
|
★Solar &Wind Power System
|
|
|
|
|
||||
|
★Golf Cart
|
|
|
|
|
||||
|
★Electric Vehicle , E-bike, E-rickshaw etc
|
|
|
|
|
||||
|
★Lighting
|
|
|
|
|
||||
