Quick Details
-
Coil Number:
-
6
-
Usage:
-
voltage conversion
-
Coil Structure:
-
Autotransformer
-
Capacity/KVA:
-
3000kva~10000kva
-
Voltage/KV:
-
11kv 22kv 33kv
-
Electricity/A:
-
customized
-
Connection group label:
-
Dyn11 / Yyn0
-
impedance voltage:
-
customized
-
No-load loss /KW:
-
customized
-
Rated frequency:
-
50Hz/60Hz
-
Type of cooling:
-
ONAN oil is self-cooled
-
Phases:
-
3 Phases
-
pulse number:
-
6 pulse,12 pulse,24 pulse
-
Rated Primary Voltage:
-
33
-
Rated Secondary Voltage:
-
415
-
Power:
-
5000KW
Quick Details
-
Phase:
-
Three
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
New Electric Power
-
Coil Number:
-
6
-
Usage:
-
voltage conversion
-
Coil Structure:
-
Autotransformer
-
Capacity/KVA:
-
3000kva~10000kva
-
Voltage/KV:
-
11kv 22kv 33kv
-
Electricity/A:
-
customized
-
Connection group label:
-
Dyn11 / Yyn0
-
impedance voltage:
-
customized
-
No-load loss /KW:
-
customized
-
Rated frequency:
-
50Hz/60Hz
-
Type of cooling:
-
ONAN oil is self-cooled
-
Phases:
-
3 Phases
-
pulse number:
-
6 pulse,12 pulse,24 pulse
-
Rated Primary Voltage:
-
33
-
Rated Secondary Voltage:
-
415
-
Power:
-
5000KW
|
1. Support customization
Different countries in the world have different characteristics such as voltage, frequency, etc. Our products can be customized according to your requirements, and provide quotations, technical data and drawings. 2. After-sale guarantee All our transformers are guaranteed for at least two years, and we provide free online technical answers and installation guidance services from engineers. 3. About the product test report Each of our transformers is tested and a test report is provided before leaving the factory. 4. About the product catalog The transformer capacity and voltage shown in the product details are common parameters and are only for reference, in fact, we customize them according to customer requirements. 5. Company address No. 21, Jinshui Road, Zhengdaong New District, Zhengzhou City, Henan Province, China |
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
