- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Shunli Motor
-
Model Number:
-
RS-775
-
Torque:
-
customized
-
Speed:
-
Max 25000rpm
-
Current:
-
Max 3A
-
Rated Torque:
-
1.2kg.cm
-
Size:
-
67*42.2mm
-
Brush Type:
-
Carbon brush or Metal brush
-
Magnet:
-
Strong or Normal one for option
-
shaft:
-
customized
-
Rated Voltage:
-
12V
-
Product Name:
-
SRS-775SA DC Motor
-
Certification:
-
CCC
Quick Details
-
Speed(RPM):
-
customized
-
Continuous Current(A):
-
customized
-
Efficiency:
-
70%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Shunli Motor
-
Model Number:
-
RS-775
-
Torque:
-
customized
-
Speed:
-
Max 25000rpm
-
Current:
-
Max 3A
-
Rated Torque:
-
1.2kg.cm
-
Size:
-
67*42.2mm
-
Brush Type:
-
Carbon brush or Metal brush
-
Magnet:
-
Strong or Normal one for option
-
shaft:
-
customized
-
Rated Voltage:
-
12V
-
Product Name:
-
SRS-775SA DC Motor
-
Certification:
-
CCC
powerfull 20000rpm rs 775 mini high speed 24 volt dc motor
Product Details
Motor Customized Specification, Please contact me.
Reference Drawing
------ RS - 755 H
------ RS - 775 H
The length of shaft can be customized, Please contact me.
|
PMDC MOTOR Technical Date |
|||||||||||
|
Model |
|||||||||||
|
Operating Range
|
Nominal
|
Speed |
Current |
Speed |
Current |
Torque |
Power |
Current |
Torque |
||
|
RPM |
A |
RPM |
A |
mN.m / gf.cm |
W |
A |
mN.m / gf.cm |
||||
|
RS-770H |
8523R |
6.0~12.0 |
12 VDC |
15000 |
2.2 |
13177 |
15.91 |
81/826.2 |
111.8 |
115 |
666.9/6802 |
|
RS-775H |
25110R |
6.0~24.0 |
24 VDC |
3478 |
0.15 |
2925 |
0.75 |
44.4/452.9 |
13.35 |
4.07 |
245.7/2506 |
1.Q: Are you trading company or manufacturer?
A: We're factory. We specialize in micro dc motor and dc gear motor for more than 14 years.
2.Q: What is the payment term for a new customer?
A: We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Master Card, Visa, etc. Customer also can pay with PayPal or TT etc.
3.Q: I can't find a suitable motor on your website, can you customize the motor for me?
A: Yes, we can customize a suitable motor according to our customer's requirements.
4.Q: Do you have certificates for the motors?
A: Yes, we have CE, FCC, ISO, etc. If you have the other certificates requirement, we can apply it for you.
5.Q: How is your Quality Control?
A: We have professional checking staff on every production line process. After finishing the whole motor, we have the entire quality machine to test the motor. Such as Hardness Tester, 2.5D Image Tester, Salt Spray Chamber, Life Tester, Temperature Test Machine, and Noise tester etc.
