Quick Details
-
Warranty:
-
2 years
-
Brand Name:
-
aikon
-
Model Number:
-
CHLF2-2, CHLF
-
Place of Origin:
-
China
-
Power:
-
0.37kw-4.4kw
-
motor:
-
induction motor
-
Material:
-
Iron/SS304/SS316L/SS904
-
Pump Type:
-
horizontal centrifugal pump
-
Frequency:
-
50/60HZ
-
Horsepower:
-
0.5HP~6HP
-
Seal:
-
Cartridge mechnical seal
-
Connection:
-
Flange/Thread connection
-
Temperature:
-
-15~+180℃
-
Flow range:
-
0.6~16m³/h
-
Head range:
-
6~60m
Quick Details
-
Application:
-
Developing World Water Solutions, HVAC OEM, Irrigation and Agriculture
-
Pressure:
-
Max 5~6 bar
-
Voltage:
-
220v/380v
-
Warranty:
-
2 years
-
Brand Name:
-
aikon
-
Model Number:
-
CHLF2-2, CHLF
-
Place of Origin:
-
China
-
Power:
-
0.37kw-4.4kw
-
motor:
-
induction motor
-
Material:
-
Iron/SS304/SS316L/SS904
-
Pump Type:
-
horizontal centrifugal pump
-
Frequency:
-
50/60HZ
-
Horsepower:
-
0.5HP~6HP
-
Seal:
-
Cartridge mechnical seal
-
Connection:
-
Flange/Thread connection
-
Temperature:
-
-15~+180℃
-
Flow range:
-
0.6~16m³/h
-
Head range:
-
6~60m
Products Description
Product Paramenters
|
Working Principle:
|
Centrifugal
|
|
Main applications:
|
Water, Chemical
|
|
Driver:
|
Electric motor
|
|
Power Specs:
|
220-240V single phase, 220-240V/380-415V three phase
50Hz or 60Hz |
|
Max.permissible fluid temperature:
|
-15°C to +70°C(hot water type max 110°C)
|
|
Type of connection:
|
Inlet thread, hose, flange
|
|
Installation position:
|
Horizontal
|
|
Casing parts material:
|
Stainless steel 304 or 316
|
|
Shaft seal type:
|
Mechanical seal
|
|
Maximum drive rating:
|
4KW(6HP)
|
|
Maximum caliber:
|
50mm(2inch)
|
|
Maximum discharge-side pressure:
|
0.6MPa(6bar)
|
|
Maximum head:
|
60m(196.8ft)
|
|
Flow rate range:
|
0.5-28m3/h(2.2-123.20US.GPM)
|
