Minew Low Power Consumption Waterproof Bluetooth Eddystone Nordic chipset Beacon itag bluetooth beacon

Minew Low Power Consumption Waterproof Bluetooth Eddystone Nordic chipset Beacon itag bluetooth beacon

FOB Reference Price: Get Latest Price

≥2 Pieces

US $1

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Waterproof:: IP67

Battery Model:: 2 x AA

Operation Voltage:: 1.8-3.6V

Transmission Circuit:: 10.5mA (Max.)

Transmission Range:: 200 meters

Antenna:: 50ohm

Accessories:: Adhesive

Net Weight:: 50.0g

Size:: Bluetooth ibeacon 72x45x22 mm

Transmission power range:: -30dBm to +4dBm

Quick Details

Chipset:: Other

Application:: Indoor location,asset management

Place of Origin:: Guangdong, China

Waterproof:: IP67

Battery Model:: 2 x AA

Operation Voltage:: 1.8-3.6V

Transmission Circuit:: 10.5mA (Max.)

Transmission Range:: 200 meters

Antenna:: 50ohm

Accessories:: Adhesive

Net Weight:: 50.0g

Size:: Bluetooth ibeacon 72x45x22 mm

Transmission power range:: -30dBm to +4dBm

Product Description

Bluetooth ibeacon is a very popular and modern iBeacon with ARM core chipset nRF52832/nRF52810 and leverage BLE 5.0 technology; it has a soft-touch round case, accurate hardware and robust firmware.

Bluetooth ibeacon is designed for the commercial advertising and indoor location-based service.
MiniBeacon can be heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile apps.

Compatibility
- Supported iOS 7.0+ and Android 4.3+ system; - Compatible with Apple iBeaconTM standard; - Compatible with all Bluetooth 4.0 (BLE) devices;

Long Battery Lifetime and Battery Level
- 5 years, with the default settings;
- LED will be flashing when battery low;
- Easy to get the real-time battery level notification;

Soft-reboot
- Reboot the device via command without any tools;

OTA and J-Link
- Supported upgrade via Over-The-Air;
- Reserved J-Link port on the board for programming; Connection Mode
- Advertising mode, non-connectable;

Configure APP

Appstore/Google Play :BeaconSET+

Parameters

Item	Value	Remarks
Firmware	BLE 4.0 Stack	V1.4x
Battery Model	2xAA	1000mAh, 3.0V
Operation Voltage	1.8-3.6V	DC
Transmission Circuit	10.5mA (Max.)	Tested at 0dBm transmission power
Transmission Range	200 meters	Maximum
Antenna	50ohm	On board / PCB Antenna
Accessories	Adhesive	1pc, high-strength, 3M brand
Output Power	0 dBm	Default setting, programmable

Package

Certifications

We are an ISO9001:2008 certified manufacturer focusing on RF / Wireless products such as 2.4GHz BLE 4.0 related products.

Our Service

Minew only focus on designed and manufactured many different high quality and low cost iBeacons hardware and one-stop services.
1. Schematic design;
2. Mold design;
3. PCB layout;
4. Firmware design;
5. Production and assembly.
Warmly welcome the OEM and ODM projects.
