- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
LNA
-
Model Number:
-
LNA-G200
-
Engine:
-
200cc automatic, 200cc
-
Drive Mode:
-
Chain
-
Wheel Size:
-
12"
-
Oil Tank Capacity:
-
12L
-
Maximum Speed:
-
75km/h
-
Displacement:
-
200cc
-
Brake Type:
-
Hydraulic Disc Brake
-
Dimensions:
-
2530*1457*1426mm
-
Wheelbase:
-
1980mm
-
Drive:
-
Chain drive
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Engine type:
-
4 Stroke
-
Wheels:
-
12"
-
Seaters:
-
2
-
Top speed:
-
75km/h
Quick Details
-
Type:
-
Pedal Go Karts
-
Engine Capacity:
-
50-200CC
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
LNA
-
Model Number:
-
LNA-G200
-
Engine:
-
200cc automatic, 200cc
-
Drive Mode:
-
Chain
-
Wheel Size:
-
12"
-
Oil Tank Capacity:
-
12L
-
Maximum Speed:
-
75km/h
-
Displacement:
-
200cc
-
Brake Type:
-
Hydraulic Disc Brake
-
Dimensions:
-
2530*1457*1426mm
-
Wheelbase:
-
1980mm
-
Drive:
-
Chain drive
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Engine type:
-
4 Stroke
-
Wheels:
-
12"
-
Seaters:
-
2
-
Top speed:
-
75km/h
Product Description
Specification
|
Model Number
|
LNA-G200
|
Engine
|
200cc
|
|
Size
|
2530*1457*1426mm
|
Top speed
|
75km/h
|
|
Clutch
|
Automatic
|
Start
|
Electric
|
|
Wheelbase
|
1980mm
|
Cooling
|
Oil cooled
|
|
Weight
|
345kg
|
Max weight load
|
200-300kg
|
|
Front track
|
278
|
Rear track
|
177
|
|
Battery
|
12v,12AH
|
Fuel Tank
|
12L
|
|
Brake
|
Hydraulic Disc Brake
|
Front wheel
|
21*7-12
|
|
Rear wheel
|
22*10-12
|
Minimum turning radius
|
3.5m
|
|
Color
|
Black,Green,Red etc
|
Packing size
|
2300*1460*865mm
|
|
Engine model
|
xy170mm-k
|
Clearance
|
285mm
|
|
Engine type
|
4 stroke
|
Acrot orque
|
17nm/5000rpm
|
|
Cylinder diameter,stroke
|
70*66.8mm
|
Power
|
12.5kw
|
|
Compression ratio
|
9:1
|
|
|
Detailed Pictures
Driver Seat
The roomy driver-seat provides spacious space for the riders even you are tall and strong ,the knees and legs will be comfortable when drive.
Electric start and Lights
Full Lights and switches including steering lights and head lights etc.
The Sporty Seats
The sporty seater with 5-points seat belts,it provides much more safety when drive
Automatic Engine
Close-up Picture of the Engine and Oil Cooled Radiator
The oil cooled radiator provides much better cooling performance than air cooled,especially suitable for long time ride.
Hydraulic Disc Brake
Actual Pictures
Please enjoy the actual pictures of this model buggy from our customers in over the word.such as Europe,Asia Etc
Certifications
Product packaging
Packing Picture
The packing is made by steel frame with carbon box and covered by plastic. strong enough for the transport
