Quick Details
-
Brand Name:
-
Lansitec
-
Supplier Type:
-
Original
-
Product name:
-
Bluetooth Beacon
-
Type:
-
BLE Module
Quick Details
-
Application:
-
Indoor location/asset tracking etc.
-
Model Number:
-
100-02395
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Lansitec
-
Supplier Type:
-
Original
-
Product name:
-
Bluetooth Beacon
-
Type:
-
BLE Module
Product Description
Specification
|
item
|
value
|
|
Model Number
|
100-02395
|
|
Place of Origin
|
China
|
|
|
Jiangsu
|
|
Brand Name
|
Lansitec
|
|
Chipset
|
SX1276
|
|
Supplier Type
|
Original
|
|
Application
|
Indoor location/asset tracking etc.
|
|
Product name
|
Bluetooth Beacon
|
|
Type
|
BLE Module
|
|
Beacon Protocol
|
iBeacon
|
|
RF Power
|
20 to +4 dBm TX power,
configurable in 4 dB steps* |
|
Sensitivity
|
-96dBm
|
|
Advertise Interval
|
100ms ~ 10s adjustable
|
|
Bluetooth Protocol
|
Bluetooth 5.0
|
|
Coverage Range
|
120m, sight distance
|
|
Supply Capacity
|
>300k/month
|
|
Frequency
|
2.4GHz
|
|
Battery Model
|
CR2477（1000mAh) x2
|
|
Battery Capacity
|
2000mAh
|
|
Battery Life
|
5 Years （0dBm, 0.5s transmit
interval) |
|
Material
|
PC
|
|
Colour
|
White
|
|
Dimension
|
82*64*21mm （with the lug)
|
|
Weight
|
43g
|
|
Operating Temperature
|
-20℃~+70℃
Optional: 1200mAh battery, -40℃~+125℃ |
|
Ingress Protection
|
IP68
|
Packing & Delivery
Single packaging for samples, large carton box for batch packaging
